Spur suppression -60 dB
Weight Approx. 218.7g (excluding batteries)
Battery Two AA size batteries
Dimensions 170.9 × 63.5 × 30.0 mm
Operating temperature 0 °C to 50 °C
Storage temperature –20 °C to +55°C
Transmitter TX10 and HU10
Channel number 96
Channel group A or B
Oscillator type PLL synthesizer
Carrier frequencies 614 MHz - 696 MHz
Reference deviation ±5 kHz (–60 dBV, 1 kHz input)
Signal to noise ratio 70 dB or more
Spur suppression -60 dB
Voice delay 12 ms
Antenna 1/4λ wire antenna
Audio input connector
TX10: 3.5mm mini jack
HU10: none
Reference audio input level –60 dBV (MIC input, 0 dB attenuation)
RF output level 30mW/20mW/10mW selectable
Distortion 0.5% or less
Weight
TX10: Approx. 211.4g (excluding batteries)
HU10: Approx. 338.2g (excluding batteries)
Battery Two AA size batteries
Dimensions
TX10: 170.9 × 63.5 × 30.0 mm
HU10: 254.0 × 52.0 × 52.0 mm
Operating temperature 0°C to 50°C
Storage temperature –20°C to +55°C
