Attaching Accessories
1
Connect the supplied cable to the output jack.
2
Attach a belt clip. Please Refer to “Attaching Accessories"
(page 10).
3
Attach the shoe mount adapter.
①
Plug the supplied cable into
the OUTPUT jack.
②
For a secure connection, turn
to lock the connector.
①
②
①
③
②
①
Please attach the belt clip
upside-down before attach-
ing the shoe mount adapter.
②
Push the bottom of the belt
clip to make some space
between the belt clip and the
receiver.
③
Align the belt clip with the
two vertical grooves on the
shoe mount adapter and
insert the adapter in the
direction of the arrow.
④
Push the shoe mount adap-
ter in fully until the belt clip
fits into the horizontal groove
on the adapter holds.
