9. SPECIFICATIONS

p. 13

KJ50VB

Acoustics

Speakers power handling 4 x 150 W

(AES)

Max power 4 x 200 W

Impedance

Frequency range 150 Hz - 20 KHz

SPL 1W/1mt 98 dB

Maximum SPL 124 dB continuous - 130 dB peak

Coverage

Horizontal selectable : Spot (10°) / Flood (100°)

Vertical DSP dependent 10°’Narrow’ to 70° ‘Wide’, +/- 15° variable focus in ‘Narrow’ mode

Crossover

Type External Crossover required

Frequency 150 Hz, 24 dB/oct suggested minimum

Transducers

Full-range 36 x 2” neodymium magnet 0.75” VC long-excursion speakers

Audio Input

Connectors

1 x 8-pin Speakon NL8 input

1 x 8-pin Speakon NL8 Thru

Wiring

(1+ 1-) =

(2+ 2-) =

(3+ 3-) = (4+ 4-) =

Selection Switch

Coverage

Type

(with dedicated preset)

Physical

Dimensions 50.3 x 43.3 x 6.1 cm (19.80” x 17.05” x 2.40”)

Weight 10 Kg (22.5 lbs)

Notes for data

1. Maximum RMS applicable power for a musical signal, the reference signal is the one proposed by EIAJ standard.

2. Measured @4 mt then scaled @1 mt

New materials and design are introduced into existing products without previous notice. Present systems may differ in some respects

from those presented in this brochure.
