K-ARRAY KJ50vb [8/16] Pin speakon

K-ARRAY KJ50vb [8/16] Pin speakon
2 x parallel IN/OUT
8-PIN SPEAKON
AMPLIFIER
CH. 1 & 2
SPEAKON 1
AMPLIFIER
CH. 3 & 4
SPEAKON 2
SPEAKER
INPUT
7. WIRING
CH 1,2 OUT
CH 3,4 OUT
C
H
3
+
C
H
1
+
C
H
2
+
C
H
3
-
C
H
1
-
C
H
2
-
2
+
2+
1
+
1+
2
-
2-
1
-
1-
C
H
4
+
C
H
4
-
CH1
CH2
CH3
CH4
1+
1-
2+
2-
3+
3-
4+
4-
8-pin speakon
4-pin speakon
4-pin speakon
4-pin speakon
4-pin speakon
8-pin speakon
Signal input to the KJ50vb is
via an 8-pin Speakon
connector with a parallel
w i r e d T h r u o u t p u t f o r
extending to additional
cabinets. Four amplifier
channels are employed. The
recommended amplifier is
the K-Array KA7-7 four-
channel amplifier, which
supplies 350 watts/channel
into a 4 ohm load. The KA7-7
h a s D S P p r e s e t s
specifically designed for the
K J 5 0 v b , i n c l u d i n g t h e
Vertical focus and steering
features. The wiring is via 2 x
4-pin Speakon connectors.
See the wiring diagram.
To c o n n e c t t o o t h e r
amplifiers follow the same
p i n c o n f i g u r a t i o n .
For use with other DSP
controllers contact
tech@k-
array.com
p. 8
