TECHNICAL SPECIFICATIONS

Item number: CLSCUBA

Product type: LED effects projector

Type: Water effect

Number of lamps: 1

Type of lamps: 90W LED

Color temperature: Cold white 9400K

Color wheel, number of colors: 7 + open and split colors

Number of effect wheels: 2 (controlled separately)

Beam angle: Lens A 28° Lens B 40°

DMX input: 3-pin XLR, male

DMX output: 3-pin XLR, female

DMX mode: 5-channel

DMX functions: Dimmer, multi-functional strobe, color wheel, 2x effect wheel

Standalone functions: Static mode, Master/Slave mode

System settings: Display backlight on/off, DMX fail, dimmer behavior, IR remote control on/off, factory reset

Controller: DMX512, IR remote control

Control elements: MODE, ENTER, UP, DOWN

Display elements: backlit LC display

Operating voltage: 100 - 240V AC / 50 - 60Hz

Power consumption: 100W

Luminous ﬂux: 1000lm

Power supply connection: IEC in and out (out max. 6A)

Fuse: T2AL / 250V (5 x 20mm)

Ambient temperature in use: 0°C - 40°C

Relative humidity: < 85%, non-condensing

Housing material: Metal

Housing color: Black

Housing cooling: temperature-controlled fans

Dimensions (B x H x W, without mount-

ing bracket):

245 x 128 x 288mm

Weight: 5.5kg

Additional features: Twin bracket stand, IEC power cable, IR remote control included. 2 lenses with numerous

beam angles included in delivery
