11. TECHNICAL SPECIFICATIONS
SYSTEMS COBRA-2 SYSTEM COBRA-4-SYSTEM
TYPE COBRA-SUB COBRA-TOP COBRA-PWH COBRA-4-TOP COBRA-4-FAR
ORDER No
112 868 112 869 112 895 112 898 112 897
CABINET SUBWOOFER MID-HIGH CAB. SUBWOOFER MID-HIGH CAB. MID-HIGH CAB.
CABINET TYPE
VENTED PASSIVE 3-WAY HORN LOADED ACTIVE 3-WAY ACTIVE 3-WAY
IMPEDANCE 8 OHMS 8 OHMS 8 OHMS ----- -----
LO-MID-HIGH
----- ----- ----- 8 - 8 - 8 OHMS 8 - 8 - 8 OHMS
RATED POWER RMS 600 WATTS 600 WATTS 600 WATTS ----- -----
LO-MID-HIGH (WATTS)
----- ----- ----- 400 - 200 - 100 400 - 200 - 200
PROGRAM POWER 1200 WATTS 1200 WATTS 1200 WATTS ----- -----
LO-MID-HIGH (WATTS)
----- ----- ----- 800 - 400 - 200 800 - 400 - 400
SPL 1 WATT / 1 M 98 dB 100 dB 101 dB 100 dB 100 dB
max. SPL / 1 M 129 dB 131 dB 132 dB 131 dB 131 dB
FREQ. RANGE (-10dB) 38Hz - 300Hz 50Hz - 15kHz 38Hz - 160Hz 50Hz - 15kHz 50Hz - 15kHz
DISP. ANGLE 1kHz (-6dB)
----- H 120° x V 30° ----- H 120° x V 30° H 120° x V 30°
DISP. ANGLE 10kHz (-6dB)
----- H 90° x V 40° ----- H 90° x V 40° H 90° x V 5°
INT. PASS. X-OVER ----- 700Hz - 4kHz ----- ----- -----
REC. ACTIVE X-OVER
124 Hz 124 Hz 124 Hz
124Hz-700Hz-4kHz 124Hz-700Hz-4kHz
VOICE COIL PROT. SUB LOW-MID-HIGH SUB LOW-MID-HIGH LOW-MID-HIGH
COMPONENTS HIGH ----- DH 2T / HPT 94 ----- DH 2T / HPT 94
DH2T LINE ARRAY
ORDER # -----
355 391 / 357 979
-----
355 391 / 357 979
3x 355 391
COMPONENTS MID ----- C8 LINE ARRAY ----- C8 LINE ARRAY C8 LINE ARRAY
ORDER # ----- 4x 361 376 ----- 4x 361 376 4x 361 376
COMPONENTS L0W ----- DL 15 Y ----- DL 15 Y DL 15 Y
ORDER # ----- 361 142 ----- 361 142 361 142
COMPONENTS SUB EVX 180 B ----- EVX 180 B ----- -----
ORDER # 349 397 ----- 349 397 ----- -----
CONNECTORS FR ----- 4-pole 1+/1- ----- ----- -----
CONN. HIGH ----- ----- 8-pole 4+/4- 8-pole 4+/4-
CONN. MID ----- ----- 8-pole 3+/3- 8-pole 3+/3-
CONN. LOW -----
"SYSTEM"
4-pole 2+/2-
----- 8-pole 2+/2- 8-pole 2+/2-
CONN. SUB 4-pole 1+/1- ----- 4+8-pole 1+/1- ----- -----
DIMENSIONS mm (WxHxD)
600 x 615 x 717 600 x 495 x 717 615 x 910 x 823 600 x 495 x 717 600 x 495 x 717
WEIGHT 58,0 kg 55,0 kg 72,0 kg 51,0 kg 60,0 kg
CABINET 18 mm 18 mm 18 mm 18 mm 18 mm
STYLE
BIRCH PLYWOOD BIRCH PLYWOOD BIRCH PLYWOOD BIRCH PLYWOOD BIRCH PLYWOOD
OUTFIT BLACK BLACK BLACK BLACK BLACK
COATING
POLYURETHANE POLYURETHANE POLYURETHANE POLYURETHANE POLYURETHANE
STEEL GRILLE
POWDER COATED POWDER COATED POWDER COATED POWDER COATED POWDER COATED
HANDLES 2 pcs. 2 pcs. 6 pcs. 2 pcs. 2 pcs.
CASTORS 4x 100mm 4x 100mm 4x 100mm 4x 100mm 4x 100mm
WARRANTY
36 MONTHS 36 MONTHS 36 MONTHS 36 MONTHS 36 MONTHS
