Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Zipper Specifications
Model: Zipper
Voltage: 100V ~ 240V/50~60Hz
LED: 4 x 8W LEDs (1 Red, 1 Green, 1 Blue,
& 1 White)
Power Consumption: 66W
Power Cord Daisy Chain: 10 Fixtures Max. (120V)
18 Fixtures Max. (230V)
Dimensions: 18.75”(L) x 9.75”(W) x 5.25”(H)
479 x 247 x 132mm
Weight: 13 Lbs. / 6 kgs.
Beam Angle: 128 Degrees
Fuse: 7 Amp
Duty Cycle: None
DMX: 3 DMX Modes: 1 Channel Mode, 3
Channel Mode, & 11 Channel Mode
Sound Active: Yes
Working Position: Any Safe, Secure Position
Warranty: 2 Year (730 days)
Auto Sensing Voltage: This xture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.adj.com / E-mail: info@americandj.com
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
Netherlands
service@adjgroup.eu / www.adj.eu
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
ADJ Products, LLC - www.adj.com - Zipper Instruction Manual Page 26
