Zipper 1 Channel Mode - DMX Traits & Values
Channel Value Function
1 SHOWS
0 - 7 BLACKOUT
8 - 22 SHOW 1
23 - 37 SHOW 2
38 - 52 SHOW 3
53 - 67 SHOW 4
68 - 82 SHOW 5
83 - 97 SHOW 6
98 - 112 SHOW 7
113 - 127 SHOW 8
128 - 142 SHOW 9
143 - 157 SHOW 10
158 - 172 SHOW 11
173 - 187 SHOW 12
188 - 202 SHOW 13
203 - 217 SHOW 14
218 - 232 SHOW 15
233 - 247 SHOW 16
248 - 255 SOUND ACTIVE SHOWS 1-16
The UC IR infrared remote gives you control of various functions
(See below). To control the fixture you must aim the remote at the
front of the fixture and be no more then 30 feet away.
STAND BY - Pressing this button will blackout the fixture.
FULL ON - Pressing the button will put the output at full intensity.
When the button is released the output will return to the normal state.
FADE/GOBO - Invalid for this fixture.
“DIMMER +” and “DIMMER -” - Invalid for this fixture.
STROBE - This button will activate the strobe effect. If you press and
hold this button the unit will begin to strobe.
COLOR - Invalid for this fixture.
SOUND ON & OFF - These buttons activate and deactivate the
sound active mode.
SHOW 0 - Press this button to activate the show mode. Use buttons
1-9 to select your desired show. To access shows 11-16, press the
SHOW 0 button again, and use buttons 1-6 to select shows 11-16.
Zipper UC IR Remote Control
