ADJ Products, LLC - www.adj.com - Zipper Instruction Manual Page 15ADJ Products, LLC - www.adj.com - Zipper Instruction Manual Page 14
Zipper Operation
“100” being the most sensitive. Press ENTER to set your level.
Show Mode: This mode allows either a single unit or several units
linked together, to run one of 16 shows that you choose. Show mode
can run with or without sound active mode.
1. Press the MENU button until “SHND” is displayed, and press
ENTER.
2. Press the UP or DOWN buttons until you nd your desired show,
press ENTER, then press and hold the MENU button for at least 3
seconds to activate. After you have set your desired show, it can
be changed at any time using the UP or DOWN buttons.
Operating Modes: The Zipper can operate in three different
modes. In each mode you can run the fixture as a stand alone
fixture or in a master/slave confiugration. This next section will
detail the differences in the operating modes.
• Sound Active mode -
The fixture will react to sound, chasing through the built-in programs.
• Show mode -
The fixture will run one of 16 shows.
• DMX control mode -
This function will allow you to control each individual fixtures traits
with a standard DMX-512 controller.
Universal DMX Control: This function allows you to use a Elation®
universal DMX-512 controller to control the chases and patterns,
dimmer and strobe. A DMX controller allows you to create unique
programs tailored to your individual needs.
1. The Zipper has 3 DMX Modes. See pages 17-20 for detailed
description of the DMX modes, values, and traits.
2. To control your fixture in DMX mode, follow the set-up procedures
on pages 5-7 as well as the set-up specifications that are includ-
ed with your DMX controller.
3. Use your DMX controller’s faders to control the various DMX fix-
ture traits.
4. Follow the instructions on page 9 to set your DMX channel mode
and the DMX address.
5. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
6. For help operating in DMX mode consult the manual included
with your DMX controller.
Sound Active Mode: This mode allows either a single unit or several
units linked together, to run to the beat of the music.
1. Press the MENU button until “SOUN” is displayed, and press
ENTER. Press the UP or DOWN buttons so that “ON” is dis-
played and press ENTER.
2. To adjust the sound sensitivity level press the MENU button until
“SENS” is displayed, and press ENTER. Use the UP or DOWN
buttons to adjust the sensitivity level, “0” being least sensitive,
Zipper Operation
Master-Slave Conguration This function will allow you to link up
to 16 units together and operate without a controller. The units will
be sound activated. In Master-Slave operation one unit will act as the
controlling unit and the others will react to the controlling units pro-
grams. Any unit can act as a Master or as a Slave.
1. Using approved DMX data cables, daisy chain your units togeth-
er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector
is the output. The rst unit in the chain (master) will use the female
XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-
tor at the last fixture.
2. On the Master unit press the MENU button until “SLND” is dis-
played, and press ENTER. Use the UP and DOWN buttons to
scroll to the “MAST” setting and press ENTER.
3. After setting the Master unit to the master setting find your
desired operating mode.
4. On the slave units press the MENU button until “SLND” is dis-
played, and press ENTER. Choose either “SL 1” or “SL 2” and
press ENTER. See page 10 for more info.
5. The slave units will now follow the Master unit.
Zipper Master-Slave Set Up
