American DJ® - www.americandj.com - Revo Sweep™ Instruction Manual Page 10American DJ® - www.americandj.com - Revo Sweep™ Instruction Manual Page 9
Revo Sweep™ System Menu Revo Sweep™ System Menu
System Menu: When making adjustments you can press
ENTER to conrm your setup or you can wait 8 seconds for
automatic setup. To exit without making any adjustments
press the MENU button.
ADDR - DMX Address Setting.
1. Tap the either the MENU, UP, or DOWN buttons until “ADDR”
is displayed, press ENTER.
2. “1” will now be displayed and ashing. Press the UP or
DOWN buttons to nd your desired address. Press ENTER to
set your desired DMX address.
CHND - This will let you the DMX Mode you want to run.
You can choose between 3 channel mode and 28 channel
mode.
1. Tap the MENU button until “CHND” is displayed, press
ENTER. Either “3CH” or “28CH ” will be displayed.
2. Tap the UP or DOWN buttons until your desired DMX chan-
nel mode is displayed, press ENTER to conm. See page 7 for
DMX Channel modes and traits.
SLND - This will let you set unit as a slave in a master/
slave conguration.
1. Tap the MENU button until “SLND” is displayed, press
ENTER. Either “MAST”, “SL 1”, “SL 2”, “SL 3”, or “SL 4” will be
displayed.
2. Tap the UP or DOWN buttons until your desired mode setting
is displayed, press ENTER to conm.
Note: Each slave mode is a different light show.
NOTE: In a Master/Slave conguration you can set one xture
to Master and then set the next xture to “SL 2”, the xtures will
now have contrast movement to each other.
Sh 0 - Sh 11 - Show modes 0 - 11 (Factory programs).
1. Tap the MENU button until “ShNd” is displayed, press
ENTER.
2. “Sh X” will now be displayed, “X” representing a number
between 1-11. Programs 1-11 are factory programs, while “Sh
0” is random mode. Press the UP or DOWN buttons to nd your
desired show and press ENTER to conrm.
SOUN - Sound Active mode.
1. Tap the MENU button until “SOUN” is displayed, press
ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to activate sound active mode, or
“OFF” to deactivate sound active mode.
3. Press ENTER to conrm.
BLND - Blackout or Stand by mode.
1. Tap the either the MENU button until “BLND” is displayed,
press ENTER. Either Yes or No will be displayed.
2. To activate Blackout tap the UP or DOWN buttons until Yes is
displayed, press ENTER to conm and exit. The xture will now
be in Blackout mode. To deactivate Blackout mode, select No
and press Enter.
LED - With this function you can have the LED display
turn off after 10 seconds.
1. Tap the MENU button until “LED” is displayed, press ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or
DOWN buttons to select “ON” to keep the LED display on at
