American DJ® - www.americandj.com - Revo Sweep™ Instruction Manual Page 11
American DJ® - www.americandj.com - Revo Sweep™ Instruction Manual Page 12
Operating Modes: The Revo Sweep™ can operate in three dif-
ferent modes.
• Sound Active mode -
The unit will react to sound, chasing through the built-in programs.
• Show mode -
Select one of 11 preprogrammed shows.
• DMX control mode -
This function will allow you to control each individual fixtures traits
with a standard Elation® DMX-512 controller.
Universal DMX Control: This function allows you to use a univer-
sal DMX-512 controller to control the colors, chases. chase speed,
and strobe. A DMX controller allows you to create unique programs
tailored to your individual needs. The Revo Sweep™ has two DMX
channel modes; a 3 channel mode and 28 channel mode.
1. To control your fixture in DMX mode, follow the set-up procedures
on pages 5-7 as well as the set-up specifications that are includ-
ed with your DMX controller.
2. Use the controller’s faders to control the various DMX fixture traits.
3. Follow the instructions on page 9 to set the DMX address and
choose your desired DMX Channel mode.
4. For longer cable runs (more than a 100 feet) use a terminator on
the last fixture.
5. For help operating in DMX mode consult the manual included
with your DMX controller.
6. The optional UC3 Controller (not included) may be used to control
different functions including blackout.
Sound Active Mode:This mode allows either single unit or sev-
eral units linked together, to run to the beat of the music.
1. Tap the MENU button until “SOUN” is displayed, and press
ENTER. Tap the UP or DOWN buttons so that “ON” is dis-
played and press ENTER.
2. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Show Mode:
1. Tap the MENU button until “SHND” is displayed, and press ENTER.
Revo Sweep™ Operation Revo Sweep™ System Menu
all times, or “OFF” to switch to have the LED display switch off
after 10 seconds.
3. Press ENTER to conrm.
IDSP - This function will reverse the display 180º.
1. Tap the MENU button until “IDSP” is displayed, press ENTER.
2. Press ENTER to “ip” the display. Press ENTER to “ip” it
again. Press ENTER when you have made your desired setup.
FHRS - With this function you can display the running time
of the xture.
1. Tap the MENU button until “FHRS” is displayed, press
ENTER.
2. The running time of the xture will now be displayed. Press
MENU to exit.
VER - With this function you can display the version soft-
ware of the xture.
1. Tap the MENU button until “VER” is displayed, press ENTER.
2. The software version will now be displayed. Press MENU to
exit.
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 46 xtures maximum. After 46 xtures you will need
to use a new power outlet. They must be the same xtures. DO
NOT mix xtures.
Revo Sweep™ Power Cord Daisy Chaining
