QUICK REFERENCE GUIDE

AC Power

This product has an auto-ranging power supply that can work with an input voltage range of 100–240 VAC, 50/60 Hz.

Power Linking

You can link up to 4 COLORado Solo Batten products at 120 V, 8 products at 208 V, or 9 products at 230 V. Never

exceed this number. Power linking cords can be purchased separately.

• When using this product in an outdoor IP65-type environment, be sure to use IP65 (or higher)

Signal Connections

You can link the COLORado Solo Batten to a controller or controller software using a DMX connection or an Ethernet

connection. If using other Art-Net™ or sACN-compatible products with the COLORado Solo Batten, you can control each

individually on a single network. See the User Manual for information about how to connect and configure the product for

these signals.

Control Personalities

The COLORado Solo Batten uses DMX, Art-Net™, and sACN for its 36 control personalities, ranging from 3CH to 160CH

RGBA EXT 9 17 24 87

RGBAW EXT 10 19 27 99

RGBAW Fine 10 20 30 120

RGBAW FULL 16 30 43 160

DMX Linking

The COLORado Solo Batten will work with a DMX controller using a 5-pin DMX serial connection. A DMX Primer is

available from www.chauvetprofessional.com.

DMX Connection

The COLORado Solo Batten uses a 5-pin DMX data connection for its DMX personalities: 1 Cell, 2 Cell, 3 Cell, or

sACN Connection

Also known as ANSI E1.31, Streaming-ACN is an Ethernet protocol that uses the layering and formatting of Architecture

for Control Networks to transport DMX512 data over IP or any other ACN compatible network. ACN is maintained by the

Professional Lighting and Sound Association (PLASA)

!

When using this product in an outdoor IP65-type environment, be sure to use IP65 (or higher) rated

data cables and secure unused ports with attached IP65 covers.

Master/Slave Connection

The COLORado Solo Batten uses the DMX data connection for its master/slave mode. See the User Manual for

information about how to connect and configure the product for master/slave operation.
