User Instructions
American DJ®
6122 S. Eastern Ave.
Los Angeles Ca. 90040
www.americandj.com
UVLED Bar16 Introduction
©American DJ® - www.americandj.com - UVLED Bar16 Instruction Manual Page 2
Rev. 11/10
Unpacking: Thank you for purchasing the UVLED Bar16 by American
DJ®. Every UVLED Bar16 has been thoroughly tested and has been
shipped in perfect operating condition. Carefully check the shipping
carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your xture for any
damage and be sure all accessories necessary to operate the unit has
arrived intact. In the case damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Do not return this unit to your dealer without rst contact-
ing customer support.
Introduction: The UVLED Bar16 is part of American DJ’s continu-
ing pursuit for creating high quality affordable intelligent fixtures. The
UVLED Bar16 is a DMX intelligent LED color wash. This wash can be
used in a stand alone mode or connected in a Master/Slave congu-
ration. The unit can also be controlled via DMX controller. This unit
has four operating modes: Static mode, program mode, sound active
mode, and DMX controlled.
Customer Support: American DJ® provides a toll free customer sup-
port line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
5:00 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ®.
PLEASE recycle the shipping carton when ever possible.
Содержание
- American d 1
- Caution 1
- Customer support 1
- Introduction 1
- Unpacking 1
- User instructions 1
- Warning 1
- Data cable dmx cable requirements for dmx operation 3
- Dmx 512 3
- Notice 3
- Ower supply 3
- Pin xlr dmx connectors 3
- Special note line termination 3
- Dmx mode 4
- Led display on off 4
- Master slave operation 4
- Operating modes 4
- Program mode sound active mode 4
- Static mode 4
- Channel value function 5
- Dimmer 0 255 0 100 5
- Program speed 1 255 slow fast 5
- Programs 0 30 dimming 31 61 strobe 62 92 increasing intensity 93 123 decreasing intensity 124 154 increase decrease intensity 155 185 three flash 186 216 one and two flash 217 247 flash 248 255 sound active 5
- Auto sensing voltage 6
- Model uvled bar16 6
