ADJ Triple Flex Руководство по эксплуатации онлайн
12/09
User Instructions
American DJ® - www.americandj.com - TripleFlex Instruction Manual Page 2
TripleFlex General Information
Unpacking: Thank you for purchasing the TripleFlex by American DJ®.
Every TripleFlex has been thoroughly tested and has been shipped in
perfect operating condition. Carefully check the shipping carton for
damage that may have occurred during shipping. If the carton appears
to be damaged, carefully inspect your xture for any damage and be
sure all equipment necessary to operate the unit has arrived intact. In
the event damage has been found or parts are missing, please contact
our toll free customer support number for further instructions. Please
do not return this unit to your dealer without contacting customer sup-
port rst.
Introduction: The TripleFlex is a DMX intelligent, triple mirror LED
scanner. The TripleFlex can operate as a stand alone fixture or in a
Master/Slave configuration. The TripleFlex has three operating modes;
sound active mode, show mode, and DMX control. For best results use
fog or special effects smoke to enhance the beams projections.
Customer Support: American DJ® provides a toll free customer
support line, to provide help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Warning! This may cause severe eye damage. Avoid looking directly
into the light source at all times!
