ADJ Triple Flex [7/10] On the slave units

American DJ® - www.americandj.com - TripleFlex Instruction Manual Page 13 American DJ® - www.americandj.com - TripleFlex Instruction Manual Page 14

Operating Modes: The TripleFlex can operate in three different

modes. In each mode you can run the fixture as a stand alone

fixture or in a master/slave confiugration. This next section will

detail the differences in the operating modes.

• Sound Active mode -

The fixture will react to sound, chasing through the built-in programs.

• Show mode -

Choose 1 of 10 show modes to run.

units together and operate without a controller. The units will be sound

activated. In Master-Slave operation one unit will act as the controlling

unit and the others will react to the controlling units programs. Any unit

can act as a Master or as a Slave.

1. Using approved DMX data cables, daisy chain your units togeth-

er via the XLR connector on the rear of the units. Remember the

Male XLR connector is the input and the Female XLR connector

is the output. The rst unit in the chain (master) will use the female

XLR connector only - The last unit in the chain will use the male

XLR connector only. For longer cable runs we suggest a termina-

Universal DMX Control: This function allows you to use a Elation®

universal DMX-512 controller to control the chases and patterns,

dimmer and strobe. A DMX controller allows you to create unique

programs tailored to your individual needs.

1. The TripleFlex can be a 4 or 9 DMX channel fixture. See pages

15-17 for detailed description of the DMX values and traits.

2. To control your fixture in DMX mode, follow the set-up procedures

TripleFlex Operation TripleFlex Operation

on pages 5-7 as well as the set-up specifications that are includ-

ed with your DMX controller.

with your DMX controller.

Sound Active Mode: This mode allows either single unit or several

units linked together, to run to the beat of the music.

1. Tap the MENU button until “SOUN” is displayed, and press

ENTER.

2. Tap the UP or DOWN buttons to choose either OFF or ON, and

press ENTER, then press and hold MENU for 3 seconds to con-

rm.

3. The optional UC3 Controller (not included) may be used to con-

trol different functions including blackout.

con rm. See pages 9-10 for more info.

3. The optional UC3 Controller (not included) may be used to con-

trol different functions including blackout.

TripleFlex UC3 Control
