UVLED Bar16 DMX Values & Functions - 3 Channels

Channel Value Function

1 DIMMER

0 - 255 0% - 100%

2 PROGRAM SPEED

1 - 255 SLOW - FAST

3 PROGRAMS

0 - 30 DIMMING

31 - 61 STROBE

62 - 92 INCREASING INTENSITY

93 - 123 DECREASING INTENSITY

124 - 154 INCREASE - DECREASE INTENSITY

155 - 185 THREE FLASH

186 - 216 ONE AND TWO FLASH

217 - 247 FLASH

248 - 255 SOUND ACTIVE

UVLED Bar16 Trouble Shooting

Listed below are a few common problems the user may encounter,

with solutions.

Unit not responding to DMX:

1. Check that the DMX cables are connected properly and are

wired correctly (pin 3 is “hot”; on some other DMX devices

pin 2 may be ‘hot’). Also, check that all cables are connected

to the right connectors; it does matter which way the inputs

and outputs are connected.

Unit does not respond to sound:

1. Quiet or high pitched sounds will not activate the unit.

If problems are not resolved; Contact American DJ® for service.

1-800-322-6337

First unplug the power. Locate and remove the unit’s power cord.

Once the cord has been removed located the fuse holder located

inside the power socket. Insert a flat-head screw driver into the power

socket and gently pry out the fuse holder. Remove the bad fuse and

replace with a new one. The fuse holder has a built-in socket for a

spare fuse be sure not to confuse the spare fuse with active fuse.

UVLED Bar16 Fuse Replacement
