©American DJ® - www.americandj.com - UVLED Bar16 Instruction Manual Page 8©American DJ® - www.americandj.com - UVLED Bar16 Instruction Manual Page 7
LED Display On/Off: To make the display stay ON all of the time
press the MODE until “ds-X” is displayed. Press the UP button so
that “ds-1” is displayed. The LED display will stay ON all of the time.
To make the display turn OFF after 10 seconds, press the UP button
so that “ds-2” is displayed. When the LED display turns OFF after 10
seconds, press any button for at least 3 seconds to turn the display
on again.
Operating Modes:
You can use the UVLED Bar16 in either a stand alone mode or a
master/slave configuration, there are 4 modes to choose from:
• Static Mode - The fixture will remain static and you can control the
intensity of the static mode.
• Programs/Sound Active Mode - In this mode you can run one of
seven programs or run a sound active mode.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller such as
as the Elation® Show Designer™.
Master-Slave Operation:
This function will allows you to link units together to run in a Master-
Slave mode. In Master-Slave operation one unit will act as the con-
trolling unit and the others will react to the controlling units built-in
programs. Any unit can act as a Master or as a Slave however, only
one unit can be programmed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the
unit. Use standard XLR microphone cables to link your units to-
gether. Remember that the Male XLR connector is the input and
the Female XLR connector is the output. The first unit in the
chain (master) will use the female XLR connector only. The last
unit in the chain will use the male XLR connector only.
2. Using the Master unit, choose your desired mode or program and
connect the “Slave” unit or units.
3. On the “Slave” unit(s) press the MODE button until “1-SL” is dis-
played. They will now follow the “Master” unit.
Program Mode/Sound Active Mode:
UVLED Bar16 Operating Instructions
In this mode you can choose one of seven programs to run or you
can choose a sound active mode. When running one of the seven
programs the speed of the program can be adjusted.
1. Plug the fixture in and press the MODE button until “3XXX” is
displayed.
2. Using the UP or DOWN buttons select one of the seven programs.
If you want to run sound active mode, press the UP or DOWN but-
tons until “3-So” is displayed.
3. To adjust the speed of your selected program, press the MODE
button once more so that “SP-X” is displayed. Now use the UP or
DOWN buttons to adjust the speed. One being the slowest, nine
being the fastest.
Static Mode:
In this mode the UV light will remain static. You can adjust the inten-
sity in this mode as well.
1. Plug the fixture in and press the MODE button until “2XXX” is dis-
played.
2. Press the UP or DOWN buttons to adjust the intensity of the light.
DMX Mode:
Operating through a DMX controller give the user the freedom to cre-
ate their own programs tailored to their own individual needs.
1. This function will allow you to control each individual fixture’s
traits with a Elation® DMX 512.
2. Press the MODE button until “1.XXX” is displayed. Press the UP
or DOWN buttons to select your desired address. Once you have
found your desired DMX address, plug in the fixture via the XLR
connections to any standard DMX controller.
3. Please see pages 10-13 for DMX values and traits.
UVLED Bar16 Operating Instructions
