Infiniti FX35 (2010) [209/508] Manual operation
![Infiniti FX35 (2010) [209/508] Manual operation](/views2/1986554/page209/bgd1.png)
2. Turn the temperature control dial to set
the desired temperature.
● To quickly remove ice from the outside of the
windows, push the fan speed increase but-
ton “
” and set it to the maximum
position.
● As soon as possible after the windshield is
clean, push the “AUTO” button to return to
the auto mode.
● When the “
” front defroster button is
pushed, the air conditioner will automati-
cally be turned on at outside temperatures
above 23°F (⫺5°C) to defog the windshield,
and the air recirculate mode will automati-
cally be turned off.
Outside air is drawn into the passenger
compartment to improve the defogging per-
formance.
Manual operation
Fan speed control :
Push the fan speed increase “
”orde-
crease “
” buttons to manually control the
fan speed.
Push the “AUTO” button to return to automatic
control of the fan speed.
Air recirculation :
Push the intake air control button to recirculate
interior air inside the vehicle. The indicator light
on the “
” side will illuminate.
The air recirculation mode cannot be activated
when the air conditioner is in the front defrost-
ing mode “
”.
Outside air circulation :
Push the intake air control button to draw
outside air into the passenger compartment.
The indicator light on the “
” side will turn
off and “
” (if so equipped) will illuminate.
Automatic intake air control :
In the AUTO mode, the intake air will be con-
trolled automatically. To manually control the
intake air, push the intake air control button.
● Without Advanced Climate Control System
(ACCS):
To return to the automatic control mode,
push the intake air control button for about
2 seconds. The indicator lights (both air
recirculation “
” and outside air circu-
lation “
” sides) will flash twice, and
then the intake air will be controlled auto-
matically.
● With Advanced Climate Control System
(ACCS):
To return to the automatic control mode,
push the intake air control button until the
indicator light on the “
” side illumi-
nates. The Advanced Climate Control System
(ACCS) turns on and the intake air will be
controlled automatically.
Air flow control :
Pushing the “MODE” manual air flow control
button selects the air outlet to:
: Air flows from center and side ventila-
tors.
: Air flows from center and side ventila-
tors and foot outlets.
: Air flows mainly from foot outlets.
: Air flows from defroster and foot outlets.
To turn the system off :
Push the “OFF” button.
Monitor, climate, audio, phone and voice recognition systems 4-43
