Infiniti G37 Convertible (2009) [105/427] 04 03 09 tbrook
![Infiniti G37 Convertible (2009) [105/427] 04 03 09 tbrook](/views2/2009928/page105/bg69.png)
2. Turn the control knob
䊊
A
to the heat side
䊊
1
or to the cool side
䊊
2
. The indicator
light
䊊
B
on the control knob will illumi-
nate.
3. Adjust the desired amount of the air using
the control knob
䊊
A
.
4. When the vehicle’s interior is warmed or
cooled, and/or before you leave the ve-
hicle, be sure to turn the control knob to
the OFF position (center). The indicator
light
䊊
B
on the control knob goes off at
the OFF position.
To check the air filter for the climate con-
trolled seat, contact an INFINITI dealer.
CAUTION
● Do not place objects in front of the intake
inlet located behind the front seat. Doing so
could cause improper operation or interrup-
tion of the operation.
● The battery could run down if the climate
controlled seat is operated while the engine
is not running.
● Do not use the climate controlled seat for
extended periods or when no one is using
the seat.
● Do not put anything on the seat which insu-
lates heat, such as a blanket, cushion, seat
cover, etc. Otherwise, the seat may become
overheated.
● Do not place anything hard or heavy on the
seat or pierce it with a pin or similar object.
This may result in damage to the climate
controlled seat.
● Any liquid spilled on the seat should be re-
moved immediately with a dry cloth.
● The climate controlled seat has air filters. Do
not operate the climate controlled seat with-
out the air filters. This may result in damage
to the system.
● When cleaning the seat, never use gasoline,
thinner, or any similar materials.
● If any malfunctions are found or the climate
controlled seat does not operate, turn the
switch off and have the system checked by
an INFINITI dealer.
The vehicle should be driven with the Vehicle
Dynamic Control (VDC) system on for most
driving conditions.
If the vehicle is stuck in mud or snow, the VDC
system reduces the engine output to reduce
wheel spin. The engine speed will be reduced
even if the accelerator is depressed to the floor.
If maximum engine power is needed to free a
stuck vehicle, turn the VDC system off.
To turn off the VDC system, push the VDC OFF
switch. The
indicator will illuminate.
Push the VDC OFF switch again or restart the
engine to turn on the system. (See “VEHICLE
DYNAMIC CONTROL (VDC) SYSTEM” in the “5.
Starting and driving” section.)
SIC1881
VEHICLE DYNAMIC CONTROL (VDC) OFF
SWITCH
2-38 Instruments and controls
췽 —
—
04/03/09—tbrooks
