JENSEN Jensen NOS Aluminium foil [4/23] Copper foil paper in oil capacitor selection

Tin foil paper in oil capacitor selection,

working voltage 630 VDC

Capacitance µF Dimensions in mm Ø D x L

0.0015 14 x 35

0.01 14 x 35

0.015 14 x 35

0.022 14 x 35

0.033 14 x 35

0.047 16 x 35

0.068 16 x 35

0.1 16 x 35

0.15 20 x 36

0.22 25 x 36

0.33 30 x 36

0.47 25 x 52

1.0 35 x 54

Copper foil paper in oil capacitor selection

Capacitance µF

630 VDC 1000 VDC

0.0015 14 x 25 14 x 25

0.01 14 x 25 14 x 25

0.015 14 x 25 14 x 35

0.022 14 x 33 14 x 35

0.033 14 x 33 16 x 35

0.047 16 x 35 16 x 35

0.068 16 x 35 18 x 35

0.1 16 x 35 22 x 35

0.15 22 x 35 25 x 35

0.22 25 x 35 30 x 35

0.33 30 x 35 25 x 55

0.47 22 x 55 or 35 x 35 30 x 55

1.0 35 x 55 40 x 55

2.2

4.0 60 x 65

Industrivej 4. DK-2605 Broendby Denmark

Phone: +45 43271685 Fax: +45 43271699

www.jensencapacitors.com audio@jensencapacitors.com

Drawing no.: 101-12221 Page 3 of 4

Description: Metal foil/paper in oil capacitor

Rev.: 3 Date:22.08.2000. Approved: JJ
