Construction: TYPES MPA are metallized capacitors of high quality, impregnated under high vacuum.
Hermetically sealed in aluminium tubes with
axial tinned copper leads. If dielectric faults should develop due to conducting
particles, or if a momentary surge of voltage should puncture the dielectric, self
healing property functions to clear and isolate the fault. The capacitor then continues to
operate normally in the circuit without interruption. Radial performance in aluminium
can are available on request.
The capacitors are supplied with an insulation sleeve, but in applications where the
sleeve distort the sound, we can deliver without sleeve.
Capacitance tolerance
: C < 1 µF : -10/+20%
C ≥ 1 µF : -10/+10%
5% tolerance, special tolerances and matching are available on request.
Operating temperature range
: -40/+85°C
Max. relative humidity:
95%
Max. ripple voltage
: The sum of the peak ripple voltage and the applied DC voltage should not exceed
the DC rating of the capacitor.
Power factor (loss factor)
: tg δ < 0.008 at 1 kHz
Test voltages
: terminal to terminal and terminals to container 1.5 X Un.
Industrivej 4. DK-2605 Broendby Denmark
Phone: +45 43271685 Fax: +45 43271699
www.jensencapacitors.com audio@jensencapacitors.com
Drawing no.: 101-12222
Page 3 of 3
Description: Speaker capacitors
Rev.: 1 Date: 29.05.00
Approved: JJ
Capacitance
µF
Dimension Ø D x L
in mm
1 14 x 45
2,2 18 x 45
3,3 25 x 45
4,7 25 x 45
5,6 30 x 45
7,0 25 x 62
8,0 25 x 62
10 30 x 62
14 35 x 62
15 35 x 62
22 40 x 65
25 45 x 65
