Sharp KCG41RW [25/28] On timer off timer

Sharp KCG41RW [25/28] On timer off timer
E-9
Select the length of time you want. The unit automatically
stops once the selected time is reached.
Select the length of time you want. The unit automatically
starts once the selected time is passes.
(with the unit OFF)
(with the unit ON)
2hour
10hour
6hour
14hour
4hour
12hour
8hour
CANCELLATION
2hour1hour 4hour 8hour
CANCELLATION
ON TIMER OFF TIMER
PATROLLING FUNCTION
The sensor detects a state requiring attention to room temperature and humidity during operation and tells it with
Patrolling Light. Both "Dry and Low temperature patrolling" and "High temperature and High humidity patrolling"
work. (This function informs a room condition. The unit cannot adjust temperature or lower humidity)
It tells that the room is dry or the room temperature is low.
When Patrolling Light turns to red, the unit operates with airow a little stronger during Intelligent mode (Auto mode).
Material source: Dr. Makoto Shoji, Director of Shoji internal medicine and pediatrics clinic
in Sendai City, Miyagi Prefecture, Japan
Right gure Absolute humidity
*1
Virus environment Survival rate
*2
(1) Over 11 g
Environment which is less suitable for
viruses to survive
0 % to small percent
(2) 11 g or less Environment where viruses can survive 5 %
(3) 7 g or less
Environment which is suitable for
viruses to survive
20 %
• It does not notify of the existence of viruses themselves.
• Patrolling Light's illuminating "Green" does not assure
prevention of infection. Use it as a reference to make an
environment to prevent infection during typical daily life.
• While adjusting humidity to approximately 55 % to 65 %
during operation in Intelligent mode (Auto mode), the
unit controls humidication, but does not make changes
according to the virus' environment.
*1 The absolute humidity is the total mass of water vapor present in 1
m
3
of air regardless of
temperature and is expressed in g. While humidity generally used for a weather forecast is called
relative humidity, which is the ratio of the partial pressure of water vapor to the equilibrium vapor
pressure of water at a given temperature and is expressed in %. Therefore, the absolute humidity is
approximately 8 g at 15
o
C
and 18 g at 30
o
C
even at the same relative humidity of 60 %.
*2 Survival rate of viruses emitted in air after 6 hours under each environment.
Patrolling
Light
If the beeping sound is set to "ON". (Ref. E-12)
Indoor environment
Temperature
and humidity
area (Figure
below)
Humidity / Temperature
Monitor
(for 30 seconds)
Beeping sound
Red
"%" Light turns on
Beep (once)
Dry
(3)
"
o
C" Light ashing
Beep (once)
Low temperature
Green
(Normal)
None
Not dry or low
temperature
(1)·(2)
DRY AND LOW TEMPERATURE PATROLLING
NOTE
When the room is dry and the room temperature is low, viruses survive more easily. We recommend
that you increase humidity with humidication setting and temperature using heating appliances
according to your room environment.
          



























         



Temperature
(
o
C)
Relative humidity (%)
ENGLISH
E-10
Humidity Temperature Wattage
OFFON
When the Plasmacluster function is ON, the Plasmacluster
Ion light on the Front Display is on. (Ref.E-6)
SELECTING DISPLAY
PLASMACLUSTER ION ON/OFF
more
3 sec.
more
3 sec.
(with the unit ON)
PATROLLING FUNCTION
The beeping sound of Patrolling Function is set to "Off" at the default. You can change it to "On" or "Cancel
Patrolling Function". (Ref. E-11, E-12)
It tells high temperature and high humidity. When Patrolling Light turns to orange or red, the unit stops humidication
automatically. (However, it is in MAX/MED/LOW mode, it does not stop humidication)
We recommend that you drink some water or lower the room temperature.
Guideline for preventing heatstroke in daily life <Source: website of Japanese Society of Biometeorology>
Temperature
standard
Overview of life
activities to be noted
Precautions
D Danger
Risks that could occur
in all life activities
Elderly people are highly likely to suffer from
heartstroke even in a resting state. Avoid going out
and move to a cooler room.
C
Heavy alert
Avoid blazing sun when going out and pay attention
to an increase of room temperature when staying in
a room.
B Alert
Risks that could occur
in middle level or higher
life activities
Rest regularly when doing exercise or intense work.
A Caution
Risks that could occur
in hard life activities
Generally the risk is low, but people may suffer
when doing hard exercise or hard work.
This is not a function to prevent heatstroke. Please use this function as an assistance.








































               

               

$
%
&
'
Relative humidity (%)
Temperature
(
o
C)
HIGH TEMPERATURE AND HIGH HUMIDITY PATROLLING
NOTE
Patrolling
Light
If the beeping sound is set to "ON". (Ref. E-12)
Indoor environment
Temperature
and humidity
area (Figure
below)
Humidity / Temperature
Monitor
(for 30 seconds)
Beeping sound
Red(Flashing)
"
o
C" Light ashing
Beep
・・・
(for 30 seconds)
High temperature
and high humidity
D
Red
"
o
C" Light turns on
Beep
・・・
(for 30 seconds)
C
Orange
"
o
C" Light turns on
None
Relatively high
temperature and high
humidity
B
Green
(Normal)
None
Not high temperature
nor high humidity
A
