Sharp KCG41RW [28/28] Troubleshooting

E-15

How to install the Float and the Tray Panel

LIFE OF FILTERS

Filter life varies depending on the room environment,

usage conditions, and location of the unit.

Lifespan of HEPA lter and Deodorizing lter and

replacement suggestions are based on purifying

a room in which 5 cigarettes are smoked per day and

the unit's dust collection and deodorizing performance

has declined to half the level of a new lter.

We recommend replacing the lter more frequently if

the unit is used in conditions signicantly more severe

than a normal household.

•HEPA Filter About 10 years after opening

•Deodorizing Filter About 10 years after opening

•Humidifying Filter About 10 years after opening

Replacement Filter Model

Consult your dealer when purchasing a replacement

lter.

Disposing of lters

Dispose of used lters according to local laws and

regulations.

HEPA Filter material:

• Filter: Polypropylene

• Frame: Polyethylene

Deodorizing Filter material:

• Filter: Paper

• Frame: ABS resin

Humidifying Filter material:

• Filter: Rayon, polyester

Maintain only the tagged

surface. Do not clean up

the opposite surface. The

lter is fragile, so be careful

not to apply too much

pressure.

Both surfaces can be

maintained.

The lter may be broken

if being too much power

is applied on it, so please

handle it with care.

Remove the dust on the HEPA Filter and

Deodorizing Filter.

Tray Panel

Float

Replacement

Filter

KC-G61R KC-G51R KC-G41R

HEPA Filter

(1 unit)

FZ-D60HFE FZ-D40HFE FZ-D40HFE

Deodorizing

Filter

(1 unit)

FZ-G60DFE FZ-G40DFE FZ-G40DFE

Humidifying

Filter

(1 unit)

FZ-G60MFE FZ-G60MFE FZ-G60MFE

Humidifying Filter

Filter Frame (white)*

Filter Frame (gray)*

Insert the oat under

this tab.

Insert the tab on the

other side of the oat

into the hole.

Tab

Float

Cross-Section view

Insert the tab of

the oat into the hole.

Tag

KC-G61R

KC-G51R / KC-G41R

CAUTION

• Do not wash the lters. Do not expose to sunlight.

Some odors absorbed by the lters will break down over time,

causing additional odors. Depending on usage conditions, and

especially if the unit is used in environments signicantly more

severe than a normal household, these odors may become

noticeable sooner than expected.

Replace the lter in those cases or if dust is unable to be

removed after maintenance.

FILTER REPLACEMENT

HEPA FILTER /

DEODORIZING FILTER

HEPA FILTER

DEODORIZING FILTER

*Do not dispose these parts.

Shaft (gray)*

Shaft (white)*

ENGLISH

E-16

TROUBLESHOOTING

Before contact for service, review the troubleshooting chart below to make sure that the problem is not a unit malfunction.

SYMPTOM REMEDY

(the following are not due to a malfunction)

Odor and smoke persists.

• Check the lters. If they appear to be extremely dirty, clean or replace them.

(Ref. E-15)

The Cleanliness Monitor is blue

even when the air is not clean.

• The air may have been dirty when the unit was plugged in. Unplug the unit, wait

one minute, and then plug the unit in again.

The Cleanliness Monitor light is

red even when the air is clean.

• Dirty or clogged dust(sensitive) sensor openings interfere with sensor operation.

Gently clean the sensor lter or the back panel. (Ref. E-13).

The unit makes a clicking or

ticking sound.

• The unit may make clicking or ticking sounds when it is generating ions.

Air discharged from the unit

has an odor.

• Check to see if the lters are extremely dirty.

• Clean or replace the lters. (Ref. E-13, E-14, E-15)

• Use only fresh tap water. Using other water sources risks the growth of mold,

fungi, or bacteria.

The unit does not operate when

cigarette smoke is in the air.

• Make sure the unit is installed in a location in which the sensors can detect

cigarette smoke.

• Check to see if the dust(sensitive) sensor openings are blocked or clogged. If

they are blocked or clogged, clean the sensor lter or the back panel.

(Ref. E-13)

The FILTER RESET Indicator

Light is on.

• Whenever after performing maintenance or replacing the lters, connect the

power cord to an outlet and then press the Filter Reset Button. (Ref. E-13)

The Front Display is turned off.

• When Light control is set to "Auto", the light automatically turns off when the

room is dark. Moreover, when Light control is set to "Turn off", the light is always

off. If you do not want the light to be off, set Light control to the "Darker" setting.

(Ref. E-11)

The Humidify Light on the

Front Display does not light up

when the tank is empty.

• The room has reached the appropriate level of humidity and has stopped

humidifying.

• Check the styrofoam oat for impurities. Clean the Humidifying Tray. Make sure

that the unit is on a level surface. (Ref. E-14)

The water level in the tank does

not decrease or decreases

slowly.

• Check to see if the Humidifying Tray and Water Tank are correctly installed.

Check the Humidifying Filter. (Ref. E-14)

• If the lter is extremely dirty, clean or replace it. (Ref. E-15)

The Cleanliness Monitor

changes color frequently.

• The Cleanliness Monitor automatically changes color when the dust (sensitive)

sensor and odor sensor* detect impurities. If you are concerned about the

change, you can change sensor sensitivity.

(Ref. E-11,E-12) (*KC-G61R / KC-G51R)

There is a discrepancy between

the unit’s Humidity Monitor

and another hygrometer in the

room.

• There is a difference in the humidity level within the same room.

• The sensor have different measurement parameters.

• If the monitor indicates wattage or temperature, switch the display by pressing

the DISPLAY SELECT button. (Ref. E-10)

The unit PM2.5 Light does not

match weather report or other

local PM2.5 data.

• Outdoor and indoor as well as the home environment (the volume of trafc

nearby, number of stories in home, etc.) may cause a reading different than

local PM2.5 data.

C" Light ashing

• The room is suitable for viruses to survive due to low room temperature. We

recommend you adjust the temperature using heating appliances. (Ref. E-9)

• The room temperature and humidity is high. We recommend that you drink

some water or lower the room temperature. (Ref. E-10)

ERROR DISPLAY

If error occurs repeatedly, contact the Sharp Service Center.

DIGITAL INDICATION REMEDY

Make sure that the Humidifying Filter and Humidifying Tray are

properly installed, and then turn the power to ON again.

Unplug the unit, wait one minute, and then plug the unit in again.
