Bosch AL 1815 CV [8/43] Adjusting the cutting height
![Bosch AL 1815 CV [8/43] Adjusting the cutting height](/views2/2011186/page8/bg8.png)
EURO • Printed in England • BA F 016 L69 768 • AHM 30/38 • GB • OSW 02/01
English - 2
F016 L69 768 • TMS • 12.00
Coarse:
The roller brackets
4
should be set in one of three
positions according to the type of lawn:
I
for high
range for bumpy lawns,
II
for medium range for av-
erage lawns and
III
fore low range for reasonably
flat lawns. You should only need to make this adjust-
ment once, thereafter use the „Fine“ adjustment to
cut longer or shorter grass.
To change the height of cut:
1. Remove the wingnut
5
and bolt.
2. Reposition the bolt for required height of cut.
3. Refit wingnut
5
.
Fine (X):
Slacken wing nut
5
on both sides of the mower.
Move both roller brackets
4
equally to the required
height of cut.
For best results, place the lawnmower on the edge
of lawn, mow in a forwards direction. Reverse at the
end of the each turn, slightly overlapping the previ-
ous cut strip.
Note: To ensure long and reliable service, carry out
the following maintenance regularly.
Regularly check for obvious defects such as loose,
dislodged or damaged blades, loose fixings, and
worn or damaged components.
Check that covers and guards are undamaged and
correctly fitted. Carry out necessary maintenance or
repairs before using.
If the mower should happen to fail despite the care
taken in manufacture and testing, repair should be
carried out by an authorised customer service agent
for Bosch garden products.
For all correspondence and spare parts orders, al-
ways include the 10-digit part number from the
nameplate of the machine!
The cutting cylinder should be adjusted if the grass
is not cut cleanly and evenly.
Turn both adjuster knobs
7
clockwise a little at time
until the cutting cylinder
6
lightly brushes the bottom
blade
8
.
Note: The blades act like a pair of shears.
Grassbox AHM 30/38C ..................0 600 886 060
Grassbox AHM 30/38C ..................0 600 886 160
Clean the exterior of the machine thoroughly using a
soft brush and cloth. Do not use water, solvents or
polishes. Remove all grass and debris.
Turn the machine on its side and clean the blade
area. If grass cuttings are compacted in the blade
area, remove with a wooden or plastic implement.
Store the lawnmower in a dry place. Do not place
other objects on top of the machine.
We guarantee Bosch appliances in accordance with
statutory/country-specific regulations (proof of pur-
chase by invoice or delivery note).
Damage attributable to normal wear and tear, over-
load or improper handling will be excluded from the
guarantee.
In case of complaint please send the machine,
un-
dismantled
, to your dealer or the Bosch Service
Centre for lawn and garden products.
Adjusting the Cutting Height
Mowing
Maintenance
C
D
D
E
Adjusting the Blade
Accessories
After Mowing/Storage
Guarantee
F016 L69 768.book Seite 2 Dienstag, 20. Februar 2001 11:44 11
