ADJ Products, LLC - www.adj.com - Stinger Star Instruction Manual Page 18 ADJ Products, LLC - www.adj.com - Stinger Star Instruction Manual Page 19
Stinger Star
UC IR/Airstream Control
The UC IR (sold separately) infrared remote gives you control of
various functions (See below). To control the fixture you must aim the
remote at the front of the fixture and be no more than 30 feet away.
The Stinger Star is also compatible with the Airstream IR app. The
IR transmitter is available through any ADJ dealer or through the ADJ
parts website. Plug the transmitter into the headphone jack of your
iOS phone or tablet. To control your IR fixture you must raise the vol-
ume to the maximum on your iOS phone or tablet and aim the trans-
mitter at the front of the fixture and be no more than 15 feet away.
After you have purchased the Airstream IR transmitters, the app is
a free download from the app store for your iOS phone or tablet.
The app comes with 3 pages of control depending on the IR fixture
you are using. Please see below for IR functions including the corre-
sponding app page.
Works with App page 1.
STAND BY - Pressing this button will blackout the fixture. Press the
button again to return to the initial state.
FULL ON - Hold this button down to fully light up the unit. When you
let the button go, the unit will return to its previous state.
STROBE - Press and hold this button for strobing.
FADE/GOBO - This button is invalid for this fixture.
“DIMMER +” and “DIMMER -” - These buttons are invalid for this
fixture.
COLOR - Press this button to activate color mode. Use buttons 1-9
to find your desired color.
1-9 - Use buttons 1-9 to select your desired color when color mode
is active. Use buttons 1-6
SOUND ON & OFF - Use the buttons to activate and deactivate
sound active mode.
SHOW 0 - Press this button to activate show mode. Use buttons 1-6
to find your desired show.
Stinger Star
Master-Slave Set Up
With this feature you can connect the xtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 8 xtures maximum @ 120V, and 16 xtures @ 230V.
After the maximum amount of xtures has been reached, you
will need to use a new power outlet. They must be the same x-
tures. DO NOT mix xtures.
Stinger Star Power Cord Daisy Chain
Master-Slave Operation This function will allow you to link up to
16 units together and operate without a controller. In a Master-Slave
set up, one unit will act as the controlling unit and the others will react
to the controlling units programs. Any unit can act as a Master or as a
Slave.
1. Using approved DMX data cables, daisy chain your units togeth-
er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector
is the output. The rst unit in the chain (master) will use the female
XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-
tor at the last fixture.
2. On the Master unit press the MENU button until “SLND” is dis-
played, and press ENTER. Use the UP and DOWN buttons to
scroll to the “MAST” setting and press ENTER.
3. After setting the Master unit to the master setting find and set
your desired operating mode.
4. On the slave units press the MENU button until “SLND” is dis-
played, and press ENTER. Choose either “SL 1” or “SL 2” and
press ENTER. See page 13 for more info.
5. The slave units will now follow the Master unit.
