ADJ Products, LLC - www.adj.com - Stinger Star Instruction Manual Page 3
ADJ Products, LLC - www.adj.com - Stinger Star Instruction Manual Page 2
Stinger Star Features
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact ADJ Products, LLC.
During operation the housing may become extremely hot. Avoid
touching the unit with bare hands while in use.
ADJ Products, LLC will not accept any liability for any resulting dam-
ages caused by the non-observance of this manual or any unauthor-
ized modication to this unit.
Stinger Star Handling Precautions
Stinger Star Warranty Registration
The Stinger Star carries a 1 Year limited warranty. Please fill out the
enclosed warranty card to validate your purchase and warranty. You
may also register your product online at www. americandj.com. All
returned service items whether under warranty or not, must be freight
pre-paid and accompany a return authorization (R.A.) number. If the
unit is under warranty you must provide a copy of your proof of pur-
chase invoice. Please contact ADJ customer support for a R.A. num-
ber.
To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.
Stinger Star General Instructions
• 2 DMX Channel Mode’s: 2 Channel and 14 Channel)
• 3 Operating Modes - Sound Active, Show Mode, & DMX Control
• RGBWA LED’s
• Green & Red Lasers
• Internal Microphone
• Digital Display for Address and Function Setting
• Power Cord Daisy Chain
• UC IR Compatible (Not Included) & Airstream IR Compatible
(transmitter not included)
Stinger Star General Information
Unpacking: Thank you for purchasing the Stinger Star by ADJ Prod-
ucts, LLC. Every Stinger Star has been thoroughly tested and has
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your xture for any
damage and be sure all equipment necessary to operate the unit has
arrived intact. In the event damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Please do not return this unit to your dealer without con-
tacting customer support rst.
Introduction: The Stinger Star is a DMX intelligent LED moonflower,
strobe, & laser fixture. The Stinger Star has 2 DMX channel modes, a
2 channel mode and 14 channel mode. The fixture can operate in as
a stand alone fixture or in a Master/Slave set up. The Stinger Star has
three operating modes; sound active, show mode, and DMX Control.
For best results use fog or special effects smoke to enhance the beams
projections.
Customer Support: ADJ Products, LLC provides a toll free cus-
tomer support line, to provide help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.adj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@adj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! This may cause eye damage. Avoid looking directly into the
light source. Use sensible precaution.
