9
English
○ Should the saw blade stop or make an abnormal noise
while operating, promptly turn OFF the switch.
○ Always take care in preventing the power cord from
coming near to the revolving saw blade.
○ Using the circular saw with the saw blade facing
upwards or sideways is very hazardous. Such
uncommon applications should be avoided.
○ When cutting materials, always wear protective
glasses.
○ When fi nished with a job, pull out the plug from the
receptacle.
MOUNTING AND DISMOUNTING THE SAW
BLADE
CAUTION
To avoid serious accident, ensure the switch is in the OFF
position, and the power source is disconnected.
1. Dismounting the saw blade
(1) Set the cutting volume at maximum, and place the
Circular Saw as shown in Fig. 5.
(2) Depress the lock lever, lock the spindle, and remove the
hexagonal-socket bolt with the hex. bar wrench.
(3) While holding the lower guard lever to keep the lower
guard fully retracted into the saw cover, remove the saw
blade.
2. Mounting the Saw Blade
(1) Thoroughly remove any sawdust which has
accumulated on the spindle, bolt and washers.
(2) As shown in Fig. 6, the side of Washer (A) with a
projected center the same diameter as the inner
diameter of the saw blade and the concave side of
Washer (B) must be fi tted to the saw blade sides.
* Washer (A) is supplied for 2 types of saw blades
with the hole diameters of 20 mm and 30 mm.
(When buying the Circular Saw, one type of washer
(A) is supplied.)
In case the hole diameter of your saw blade does
not correspond to that of washer (A), please contact
the shop where you purchased the Circular Saw.
(3) To assure proper rotation direction of the saw blade, the
arrow direction on the saw blade must coincide with the
arrow direction on the saw cover.
(4) Using the fi ngers, tighten the hexagonal-socket bolt
retaining the saw blade as much as possible. Then
depress the lock lever, lock the spindle, and thoroughly
tighten the hexagonal-socket bolt.
CAUTION
After having attached the saw blade, reconfi rm that the lock
lever is fi rmly secured in the prescribed position.
MAINTENANCE AND INSPECTION
1. Inspecting the saw blade
Since use of a dull saw blade will degrade effi ciency
and cause possible motor malfunction, sharpen or
replace the saw blade as soon as abrasion is noted.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws
be loose, retighten them immediately. Failure to do so
could result in serious hazard.
3. Maintenance of the motor
The motor unit winding is the very “heart” of the power
tool.
Exercise due care to ensure the winding does not
become damaged and/or wet with oil or water.
4. Inspecting the carbon brushes
For your continued safety and electrical shock
protection, carbon brush inspection and replacement
on this tool should ONLY be performed by a HiKOKI
Authorized Service Center.
5. Replacing supply cord
If the replacement of the supply cord is necessary, this
has to be done by the manufacturer of this agent in
order to avoid a safety hazard.
6. Adjusting the base and saw blade to maintain
perpendicularity
The angle between the base and the saw blade has been
adjusted to 90°, however should this perpendicularity
be lost for some reason, adjust in the following manner:
(1) Turn the base face up (Fig. 7) and loosen the wing-bolt
(Fig. 3).
(2) Apply a square to the base and the saw blade and
turning the slotted set screw with a slotted-head
screwdriver, shift the position of the base to produce
the desired right angle.
7. Maintenance of the lower guard
For safe and proper working, always keep the machine
and ventilation slots clean. The lower guard must
always be able to more freely and retract automatically.
Therefore, always keep the area around the lower
guard clean. Remove dust and chips by blowing out
with compressed air or with a brush.
CAUTION
In the operation and maintenance of power tools, the
safety regulations and standards prescribed in each
country must be observed.
GUARANTEE
We guarantee HiKOKI Power Tools in accordance with
statutory/country specifi c regulation. This guarantee does
not cover defects or damage due to misuse, abuse, or
normal wear and tear. In case of complaint, please send
the Power Tool, undismantled, with the GUARANTEE
CERTIFICATE found at the end of this Handling instruction,
to a HiKOKI Authorized Service Center.
NOTE
Due to HiKOKI’s continuing program of research and
development, the specifi cations herein are subject to
change without prior notice.
IMPORTANT:
Correct connection of the plug
The wires of the main lead are coloured in accordance with
the following code:
Blue: — Neutral
Brown: — Live
As the colours of the wires in the main lead of this tool may
not correspond with the coloured markings identifying the
terminals in your plug proceed as follows:
The wire coloured blue must be connected to the terminal
marked with the letter N or coloured black. The wire
coloured brown must be connected to the terminal marked
with the letter L or coloured red. Neither core must be
connected to the each terminal.
NOTE:
This requirement is provided according to BRITISH
STANDARD 2769: 1984.
Therefore, the letter code and colour code may not be
applicable to other markets except The United Kingdom.
000BookC6SS.indb9000BookC6SS.indb9 2019/09/1917:23:472019/09/1917:23:47
