Liebherr WTes 5972-22 Vinidor [8/16] Labels

Number of bottles

Total 211 bottles

Storage diagram

for 0.75 l Bordeaux bottles to standard NF H 35-124

Labels

The appliance is supplied with one

label for each wooden shelf.

Use these to label the type of wine

stored on each shelf.

Additional labels can be obtained from

your dealer.

Click the label holder into place and

slide the label in from the side.

Important

The maximum load per wooden shelf is 35 kg.

Presentation shelf

The middle pull-out shelf in the top compartment can be used

for the presentation of wine bottles or to keep opened bottles at

the perfect temperature. The presentation shelf can be used in

both zones.

The wooden shelf above it must

be removed so that the presenta-

tion shelf can be used. Raise and

remove the shelf.

Pull the presentation shelf for-

wards as far as it will go.

The front section of the pres-

entation shelf consists of two

segments which can be raised

separately.

Raise the segment and pivot the two supports

downwards.

Bottles can be stored behind the

raised segment.

Inserting the wooden shelf

Fit the upper wooden shelf again for using the presentation shelf

for storing bottles normally (with the segments not raised).

Extend the pull-out rails as far as they will go.

Place the wooden shelf with its bore holes face down on the pins

on the pull-out rails.
