26
CHEST FREEZER
USER GUIDE
OPERATION
TEMPERATURE CONTROL
For the models BD(W)-117QX, BD(W)-177QX, BD(W)-247QX, BD(W)-247S
A green indicator on the control panel means that the compressor is on and running.
Correspondence of temperature regimes to thermostat positions is indicated in the table.
To use the fast freeze function, set the thermostat to the maximum position 4-6 hours
before placing food in the chest to achieve the lowest temperature.
F
R
E
E
Z
E
R
2
4
5
6
7
8
3
1
R
E
F
R
I
G
E
R
A
T
O
R
Mode Position Temperature
Refrigerator
1 +4 ~ +10°С
2 -3 ~ -6°C
Freezer
3 -10 ~ -13°С
4 -15 ~ -18°С
5 -18 ~ -20°С
6 -20 ~ -23°С
7 -23 ~ -25°С
8
-32°C (if the ambient temperature is not
higher than +25°C).
For the models BD(W)-297QX, BD(W)-297S, BD(W)-337QX, BD(W)-497QX,
BD(W)-337S, BD(W)-497S
When the device is connected to the network, the yellow indicator “POWE” lights up.
A green indicator “RUNNING” on the control panel means that the compressor is on and
running. Correspondence of temperature regimes to thermostat positions is indicated in
the table. To use the fast freeze function, set the thermostat to the maximum position 4-6
hours before placing food in the chest to achieve the lowest temperature.
POWER RUNNING
Mode Position Temperature
Refrigerator
1 +4 ~ +10°С
2 -3 ~ -6°C
Freezer
3 -10 ~ -13°С
4 -15 ~ -18°С
5 -18 ~ -20°С
6 -20 ~ -23°С
7 -23 ~ -25°С
8
-32°C (if the ambient temperature is not
higher than +25°C).
*The temperature values given above may differ from the actual values, depending
on the installation location of the product, the type of operation and other external factors.
ATTENTION! Do not block the air vents of the chest freezer and do not allow
them to become clogged. The continuous circulation of cold air allows you to
maintain a constant temperature inside the chamber.
