34
English
Symbol Meaning
Attention� Important�
Useful information�
Wear protective gloves�
Torque control position:
"Drilling"�
Stepless speed control�
Do not dispose of the power
tool in a domestic waste
container�
Power tool designation
[CT21081H-2, CT21081H-4, CT21082H-1.5,
CT21082H-2, CT21082H-4, CT21081HQ-2,
CT21081HQ-4, CT21082HQ-1.5, CT21082HQ-2,
CT21082HQ-4]
The power tool has been designed for hole drilling
in wood, plastic and metal, as well as for screwing
in and loosening of threaded fastening elements
(screws, bolts, etc�)� CT21081HQ-2, CT21081HQ-4,
CT21082HQ-1.5, CT21082HQ-2, CT21082HQ-4 -
these models deliver with quick-change attachments
(keyless chuck, tool holder and angle tool holder) that
allow to perform works in hard-to-reach places�
[CT21081HB-2, CT21081HB-4, CT21082HB-1.5,
CT21082HB-2, CT21082HB-4]
The power tool has been designed to unscrew and
to tighten threaded fastening elements (bolts, nuts,
screws, bolt screws, etc�)�
Power tool components
1 Battery lock *
2 Battery *
3 Universal tool holder
4 LED lamp
5 Torque regulator
6 Step speed selector switch
7 On / off switch
8 Reverse switch
9 Ventilation slots
10 Control button of the state of battery charge *
11 Indicators of the state of battery charge *
12 Belt clip *
13 Quick-change keyless chuck *
14 Quick-change tool holder *
15 Quick-change angle tool holder *
16 Charger *
17 Keyless chuck
18 Tool holder
19 Fixing bush
20 Lock of quick-change attachment *
21 Screwdriver bit *
22 Screw
23 Magnetic holder *
24 Label *
25 Indicator (red) *
26 Indicator (green) *
* Optional extra
Not all of the accessories illustrated or described
are included as standard delivery.
Installation and regulation of power tool
elements
Before execution of any procedures, centre the
reverse switch 8.
Do not draw up the fastening elements
too tight to avoid damaging the thread.
Mounting / dismounting / setting-up of
some elements is the same for all power
tool models, in this case specic models
are not indicated in the illustration.
Mounting / replacement of quick-change
accessories (see g. 1-3)
[CT21081HQ-2, CT21081HQ-4, CT21082HQ-1.5,
CT21082HQ-2, CT21082HQ-4]
Quick-change attachments 13, 14 or 15 enlarge the
area of power tool usage and allow to perform works in
hard-to-reach places (see g. 2.2).
• Move the lock 20 forward and hold it in this position
(see g. 1.1).
• Install one of quick-change attachments 13, 14 or 15
on universal tool holder 3 (see g. 1.2).
• Release the lock 20�
• Disassembly operations do in reverse sequence�
• Quick-change angle tool holder 15 can be set to
different positions (see g. 2.1).
• Quick-change keyless chuck 13 and quick-change
tool holder 14 (see g. 3) can be installed on quick-
change angle tool holder 15�
Mounting / replacement of accessories (see g. 4-8)
[CT21081H-2, CT21081H-4, CT21082H-1.5,
CT21082H-2, CT21082H-4]
With long-term use the drill bit may be-
come very warm; use gloves to remove it.
