have passed.

To activate the 24h Auto Drying and locking function at a time other than that programmed, press and

hold in the mode selection wheel a for one second.

Indicator light B will come on.

The device will operate for 2 hours and 15 minutes, and then the heating will be switched off.

This function can be deactivated at any time before the end of the 2 hours and 15 minutes, by pressing

on the mode selection wheel A.

To deactivate 24h Auto Drying and locking function, change the position of the mode selection wheel

a. At the end of the initiated cycle, the device returns to regular operating mode (indicator light B will be

on until the cycle is complete).

To stop the cycle quickly, turn the wheel to the OFF position. The 24h Auto Drying and locking function

will be deactivated.

Lock the controls: use the lock function

With this function you can fix the selected heating mode (e.g. ON mode, temperature set using the

wheel in the position). This function is designed to protect against inadvertent use of the device

(by children, etc.). To activate the lock function, press in the mode selection wheel a and hold it in this

position for more than three seconds, then release (the wheel may be in any position except the OFF

position).

Indicator light B will flash five times: the selected settings will be locked.

The pre-selected temperature value cannot be modified.

The 2-hour intense operation function is also accessible: to activate it you need to press on wheel a

(if wheel A was in the ON, or position).

To deactivate the lock function, press in the mode selection wheel a and hold it in this position for

more than three seconds, then release. Indicator light B will flash five times: the selected settings

will be locked.

In this case the position of the mode selection wheel a can be changed, but the change will not be

saved.

- If you change the position of the mode selection wheel a, indicator light B will start to flash.

- If you change the position of the temperature control wheel d, the temperature value will not

change.

Calibrating the temperature

After a few hours' operation in heating mode, depending on the selected installation method (position of

the device and its heat transfer ratio and the room surface area, insulation class, etc.), the room

temperature may differ from the temperature shown on the device. In this case, the displayed temperature

can be calibrated.

For example, wheel D has been turned to 21 °C. The thermometer shows a temperature of 20 °C.

Turn the outer disc of the temperature control wheel d, while holding its

central part.

Position the outer disc of the wheel opposite the temperature value

displayed on the thermometer (the position may change within the

range –3 °C to +3 °C).

Then turn the outer disc of the wheel to its initial position. The device

will start to adjust the temperature to a value of 20 °C.

Setting the device to anti-freezing mode.
