38
INSTALLATION LOCATION AND SURROUNDING
1. All washing and additional substances are to be kept in a safe place out of
the reach of children.
2. Do not install the machine on a carpet floor. The obstruction of the openings by
a carpet can damage the machine.
3. Keep the appliance clear from heating sources and direct sunlight to avoid
plastic and rubber parts to corrode.
4. Do not use the appliance in humid environments or rooms containing explosive
or caustic gas. In case of water leakage or water splashes let the appliance
dry in the open air.
5. The appliance must not be installed behind a lockable door, a sliding door or a
door with a hinge on the opposite side to that of the washing machine.
6. Do not operate the machine in rooms with a temperature of below 5 °C. This
can cause damages to parts of it. If it is unavoidable, make sure to drain the
water completely from the appliance after every use to avoid damages caused
by frost.
7. Never use flammable sprays or substances in the immediate proximity of the
appliance.
INSTALLATION
1. Remove all packaging material and transport bolts before using the appliance.
Otherwise, serious damage may result.
2. This appliance is equipped with a single inlet valve and can be connected to
the cold water supply only.
3. Mains plug must be accessible after installation.
4. Before washing clothes for the first time, the product shall be operated once
throughout all the procedures without any clothes inside.
5. Before using the washing machine, the product shall be calibrated.
6. Do not put any excessively heavy objects on the appliance, like water
containers or heating devices.
7. The new hose-sets supplied with the appliance are to be used and that old
hose-sets should not be reused.
8. Max. Inlet water pressure 1 MPa. Min. inlet water pressure 0.03 MPa.
ELECTRICAL CONNECTION
1. Make sure the supply cable is not trapped by the machine, it can get damaged.
2. Connect the product to a grounded outlet protected by a fuse complying with
the values in the «Technical specifications» table. The grounding installation
has to be made by a qualified electrician. Ensure that the machine is installed
in accordance with the local regulations.
3. Water and electrical connections must be carried out by a qualified technician
in accordance with the manufacturer‘s instructions and local safety
regulations.
ATTENTION
– Don´t use multiple plugs or extension cords.
– The appliance must not have an external switching device such as a timer or
connected to a circuit that is regularly switched on and off.
– Do not pull the plug out of the mains outlet if there is flammable gas around.
– Never pull out power plug with wet hands.
– Always pull at the plug, not at the cable.
– Always unplug the appliance if it is not being used.
WATER CONNECTIONS
1. Check the connections of the water inlet tubes, the water tap and the
outlet hose for possible problems due to changes of water pressure. If the
connections loosen or leak close the water tap and get it repaired. Do not use
the appliance before the pipes and hoses are installed properly by qualified
persons.
2. Glass door may become very hot during the operation. Keep children and pets
far away from the machine while it is operating.
3. The water inlet and outlet hoses have to be safely installed and remain
undamaged. Otherwise, water leakage can occur.
4. Do not remove the drain pump filter while there is still water in the appliance.
Big quantities of water can leak out, and there is a risk of scalding due to
hot water.
OPERATION AND MAINTENANCE
1. Never use any flammable, explosive or toxic solvents. Do not use gasoline
and alcohol etc. as detergents. Only select detergents that are suitable for
machine washing.
2. Make sure that all pockets are emptied. Sharp and rigid items such as
coins, brooches, nails, screws, stones etc. may cause serious damages to
this machine.
3. Remove all objects from pockets such as lighters and matches before use
the appliance.
4. Thoroughly rinse items that have been washed by hand.
5. Items that have been soiled with substances such as cooking oil, acetone,
alcohol, petrol, kerosene, spot removers, turpentine, wax and wax removers
should be washed in hot with an extra amount of detergent before being
dried in the appliance.
6. Items containing foam rubber (latex foam), shower caps, water proof textiles,
rubber backed articles and clothes or pillows fitted with foam rubber pads
should not be dried in the machine
7. Fabric softeners or similar products should be used as recommended in their
instructions.
8. Never try to open the door forcefully. The door will unlock shortly after the
end of a cycle.
9. Please do not close the door with excessive force. If it is found difficult
to close the door, please check if the clothes are properly inserted and
distributed.
10. Always unplug the appliance and close the water tap before cleaning and
maintenance and after each use.
11. Never pour water over the appliance for cleaning purpose. Risk of electric
shock!
12. Repairs shall only be carried out by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard. The producer will not
be responsible for damages caused by the intervention of not authorized
persons.
TRANSPORT
1. Before Transport:
– Bolts shall be reinstalled to the machine by a specialized person
– Accumulated water shall be drained out of the machine
2. This appliance is heavy. Transport with care. Never hold any protruding part
of the machine when lifting. The machine door cannot be used as a handle.
REQUIREMENTS FOR INSTALLATION, STORAGE, TRANSPORTATION (SHIPMENT), SALE
AND DISPOSAL
1. The appliance does not require any permanent installation or securing.
2. The manufacturer or consumer should store the appliance in suitable
packaging in heated facilities at a temperature of 5 °С to 40 °С and a maximum
relative humidity of 80 %. The storage facilities should not contain aggressive,
corrosion-provoking environments (acidic or alkaline vapors).
3. The following requirements should be observed to ensure proper
transportation of the appliance:
– remove all internal accessories from the appliance, if any are installed, and
pack them separately;
– ensure that the appliance is properly packed to retain its functionality and
exterior look (bulky appliances should be wrapped into plain or bubble
polyethylene film with corrugated cardboard inserts in sensitive places);
– securely fasten the appliance with straps to prevent its displacement within
the vehicle during transportation;
– transport the appliance only in an enclosed vehicle to eliminate any impact
from the outdoor environment;
– ensure that the appliance is handled with utmost care during loading and
unloading to keep the packaging undamaged.
4. The appliance requires careful handling to keep it from dust, dirt, mechanical
impact, moisture, fire, etc.
5. The appliance should be sold and purchased in compliance with the local
legislation.
6. Do not discard the appliance together with other domestic waste upon expiry
of its service life. Instead, it should be turned over for disposal to a specialized
recycling facility for electric and electronic equipment in compliance with the
federal or local legislation. By ensuring proper disposal of the appliance You
