39
contribute to the saving of natural resources and the prevention of damage
to the environment and human health, which may occur in case of improper
handling. Detailed information about disposal facilities suitable for your
appliance located in Your area is available from the local municipal authorities
or at a domestic waste disposal company.
7. If any malfunction of the appliance should occur, please immediately contact
an authorized service center or turn the appliance over for disposal.
Should You decide to transfer the appliance to another person, please pass the
present manual over along with it.
2. APPLIANCE DESCRIPTION
1
4
2
5
7
3
6
8
9
1. Water supply tube
2. Washing agent drawer
3. Door
4. Top cover
5. Power cable
6. Control panel
7. Drum
8. Drain hose
9. Filter
3. SCOPE OF SUPPLY
– Washing machine - 1 pc.
– Plugs - 4 pcs.
– Water supply hose - 1 pc.
– User Manual - 1 pc.
– Wrench - 1 pc.
4. OPERATING THE WASHING MACHINE
INSTALLATION LOCATION
ATTENTION
– Stability is essential for preventing spontaneous displacement of the
appliance during operation.
– Ensure that the appliance is leveled out. Allowable floor gradient – 1 °.
– Ensure that the appliance is not standing on its power cable and not jamming
it.
– The minimum clearance between the appliance and the walls or adjacent
permanently fixed objects shall be 20 mm at the sides and 100 mm at the back.
1. The washing machine should be installed on a dry, level and hard surface.
2. Keep the appliance away from direct sunlight.
3. The washing machine should be installed in a well-ventilated room.
4. The temperature in the room should not drop below 5 °С.
5. Install the washing machine away from heat sources, such as coal or gas
ovens, fireplaces or heaters. If this is not possible, install suitable heat
insulation between the appliances, lined with aluminum foil facing the heat
source. The heat shield should cover the entire surface area of the washing
machine. The washing machine should not be heated with by the heat sources.
UNPACKING THE WASHING MACHINE
ATTENTION
Packaging materials (e.g. film or plastic foam) can
present a hazard for children.
SISK OF SUFFOCATION! Store the packaging
materials out of reach of children.
While unpacking the appliance ensure that it has
not been damaged during transportation. If any
damage is revealed, do not connect the machine
– immediately contact the Manufacturer (vendor).
Check the scope of supply.
1. Remove the cardboard box and foam plastic packaging.
2. Lift the washing machine and remove the packaging from its base. Ensure that
the small foam plastic triangle is removed from the machine base. If not, lay
the appliance on a side, then manually remove the foam plastic triangle from
the bottom of the appliance.
3. Remove the tape binding the power cable to the drain hose.
4. Remove the water intake tube from the drum.
ATTENTION
Remove the four transport bolts from the back side of the machine before
operating it.
1. Unscrew the 4 transport bolt with a suitable wrench.
2. Extract the bolts, including the rubber washers, from the machine body, keep
them in case of future transportation.
3. Close the bolt holes with the supplied plugs.
