40
NOTE: Failure to remove the transport bolts will result in strong vibration and
noise, spontaneous displacement of the machine and can cause irreparable
damage to the machine.
LEVELING THE WASHING MACHINE
Level out the washing machine using the threaded
feet so that the deviation from the horizontal plane
does not exceed 1 °.
Loosen the lock nut with a wrench.
Turn the foot until it is firmly pressed against the
floor.
Adjust all 4 feet as described in Item 2 so that the machine stands level and does
not wobble. Use a construction water level to check the leveling of the machine.
STABILITY CHECK
The washing machine should not rock or wobble when pressed on the corners of
the top cover (check both diagonal directions). If the machine wobbles readjust
the feet.
Secure the feet after adjustment by tightening the lock nuts on all 4 feet.
ATTENTION
Firmly tighten the locknuts of all four feet against the machine body after
adjustment.
NOTE:
– A proper placement and leveling of the machine guarantees its long-term,
stable and reliable operation.
– The washing machine should be installed absolutely level and stably.
– The machine should not rock or wobble under load.
– Avoid contact of the machine feet with moisture. Otherwise vibration or noise
may occur.
ATTENTION
If the washing machine is installed on a carpeted floor, make sure that its
base is raised above the carpet pile. Otherwise ventilation may be hindered or
impossible.
CONNECTING TO WATER SUPPLY
ATTENTION
Connection of the appliance to water supply should only be performed by a
skilled technician.
NOTE:
– The water supply pressure should be within the range of 0,3 to 1 mPa (0,3-10
kg/cm
2
). If the pressure exceeds 1 mPa a pressure-reducing device should be
installed upstream of it.
– Do not apply excessive force when screwing the water supply tube onto the
tap.
– Regularly check condition of the tube, replace if necessary.
– Use only brand new water supply tubes for washing machines, do not use old
tubes e.g. used with the pervious machine.
ATTENTION
Connect the washing machine only to the cold water supply piping. The internal
components of the machine are not made of materials suitable for hot water.
Besides, the supply of hot water into the machine will disturb the temperature
modes during washing and cause damage to your laundry. Hot water may
contain anti corrosion additives which are detrimental to the internal parts of
the washing machine.
CONNECTING THE INLET TUBES AND VALVES
1. Check the availability of the rubber gaskets on both sides of the flexible tube.
If necessary, insert the rubber gaskets into the threaded fittings of each hose
end for sealing the connections.
2. Usually, on the water supply piping side, the tube is connected to a three-way
valve attached to the tube to provide water cutoff from the machine. Screw the
ring nut of the tube onto the valve by hand as firmly as possible, then tighten
by a quarter or half turn with a suitable tool. Do not overtighten the nut, as this
may rupture the gasket and cause a leak.
3. After connecting open the valve to flush any contaminants (dirt, dust, sand)
from the tube that may have gotten inside during installation. Collect the
water in a bucket or basin.
4. Screw the ring nut of the tube onto the washing machine inlet, then tighten it
the same way as on the water supply valve.
NOTE: Every time you open the water supply valve after connecting it to the
machine, do it slowly to prevent surge (hydraulic shock) and damage to the
internal component of the machine.
Close the water supply valve every time after using the machine to prevent leaks
and spillage.
ATTENTION
Do not try to extend the water supply tube yourselves! If the water supply tap is
located too far away from the machine, buy a longer tube.
NOTE: The washing machine can be connected to water supply via an ordinary
domestic tap. In this case all the same requirements should be observed,
besides, to avoid spillage, please ensure that the connection between the tap
and the hose is tight and secure and the tube will not come off the tap. However,
this connection method is not recommended and can only be applied if a fixed
connection to water supply is not possible.
DRAIN HOSE CONNECTION
ATTENTION
Connection of the appliance to the drain should only be performed by a skilled
technician.
1. One end of the hose is fixed to the appliance. Do not pull it out or force it in.
2. The other (free) end of the hose can be routed into a bathtub, sink, or connected
to the drain (sewage) piping.
3. If the free end of the hose is routed into a bathtub or sink, it should be firmly
secured (e.g. with a special bathtub clamp). A loose hose can easily fall off
because of the water pressure and cause spillage.
4. When connecting the hose to the drain pipe, make sure it is not inserted too
deep so as not to obstruct the sewage flow. If the hose is too long – cut it
down to size.
5. In any case please avoid the siphon effect when connecting the machine to the
drain; otherwise the water will not stop running. For this purpose a part of the
hose should always be raised at least 60 cm above the floor.
Besides, the free end of the drain hose should not be submerged in water
(therefore please avoid connecting the hose to the sewage pipes with a
constant water flow).
