Centek CT-1957 [45/52] Auxiliary modes and functions wash end delay time selection this function allows to delay completion of the washing cycle for 3 to 24 hours in 1 hour increments for examples if...

Attention electric shock hazard if the supply cord is damaged it must be replaced by the manufacturer its service agent or similarly qualified persons in order to avoid a hazard if the machine is damaged it must not be operated unless repaired by the manufacturer its service agent or similarly qualified persons 38

Dear customer thank you for purchasing a centek brand product we guarantee flawless function of this item provided the guidelines of its operation are observed 38

English 38

Purpose of the appliance the product is intended only for home use and for textiles in household amounts suitable for machine washing this appliance is for indoor use only and not intended for built in use only use according to these instructions the appliance is not intended for commercial use any other use is considered as improper use the producer is not responsible for any damage or injuries that may result of it 38

Remark according to eu requirements the appliance can be used by children aged from 8 years and above and persons with reduced physical sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved children shall not play with the appliance cleaning and user maintenance shall not be made by children without supervision children should be supervised that they do not play with the appliance children 3 years and under shall be kept away from the appliance or continuously supervised 38

Safety precautions please read the following safety information thoroughly and follow it strictly to minimize the risk of fire or explosion electric shock and to prevent property damage personal injury or loss of life failing to follow these instructions shall void any warranty 38

The appliance should not be used by physically sensory or mentally handicapped persons including children or by persons without sufficient experience or knowledge unless such persons are under supervision or have been instructed on the use of the appliance by the persons responsible for their safety take precautions not to let children play with the appliance 38

This appliance is designed for use in domestic and similar applications in particular in personnel kitchen zones at stores offices and industrial facilities at agricultural farms by clients at hotels motels and other residential facilities in private boarding houses 38

4 2 3 5 6 9 7 8 44

A wash end delay activation indicator b child lock activation indicator c door lock indicator d displaying numeric values e the с symbol lights up when the temperature is displayed f smart mode activation indicator 44

Control panel 44

On off button 2 washing program selection button 3 drying speed selector button 4 washing temperature selector button 5 display 6 smart mode activation button 7 activation button for the delayed start mode for the latter hold down the button for 3 seconds 8 custom washing time selection button 9 start pause button for wash cycle startup or suspension 10 washing program indication lights 44

The laundry detergent should be used in accordance with the manufacturer s instructions and selected according to fabric type color degree of contamination and the washing temperature please use only detergents designed specifically for machine washing if there is too much foam reduce the amount of detergent excessive detergent produces too much foam which lowers the washing quality and overloads the motor the quantity of detergent can depend on water temperature water hardness the size and contamination degree of the items to be washed 44

Washing program and mode description 44

Attention in the event of a power failure the machine will continue the washing cycle from the moment it was interrupted when power supply resumes 45

Auxiliary modes and functions wash end delay time selection this function allows to delay completion of the washing cycle for 3 to 24 hours in 1 hour increments for examples if you have selected the cotton program without the auxiliary functions the programs takes 57 minutes and set the end delay time to 10 hours then the wash will start after 9 03 hours and complete after 10 hours this is very useful if you want to complete your laundry by a definite time e g by the time you come home or wish to postpone it for the night because of more favorable nighttime electricity tariffs in order to activate this function hold down the delayed start button for 3 seconds before starting the washing program then select the desired completion delay time the display will show the relevant indicator a timer icon to reset hold down the program button 45

Child lock function this function allows keeping the safety of your children and the appliance under control this function is activated after a program is selected and started by holding down the speed button for 3 seconds the relevant indicator will appear on the display all functions and modes of the machine will become inaccessible in order to deactivate the function repeat the same actions as for activating it the indicator will go out 45

Delayed start the function allows delaying commencement of the washing program for up to 24 hours this is very useful when you would like to finish your laundry by a certain time e g by the time you come back home or do it in the night because of a more favorable nighttime electricity tariff rate select the desired time by pressing the delayed start button if no delay is needed select 0 45

Drum cleaning the drum of the washing machine contacts dirty clothing and detergents bacteria and detergent residues can accumulate in the drum over time high humidity inside the machine which lasts for a long time after laundry completion contributes to the buildup of mould and putrid smell in order to extend the service life of the washing machine and keep the drum clean wipe the inside of the drum including the folds of the rubber seal dry after each laundry and regularly use the drum cleaning function 1 before activating the drum cleaning function ensure that there is nothing left in the drum 2 add a special drum cleaning detergent for automatic washing machines into the main wash detergent compartment 3 select the program and press the start pause button the cleaning is performed at 85 с 4 wait for the program to complete and wipe the inside of the drum with a soft dry cloth 45

Note if you set the start delay do not use liquid detergent as it is prone to hardening and can stick to the internal parts of the machine if it is not immediately dissolved in water 45

Note in order to achieve optimal washing results follow the instructions related to the maximum weight of the clothes loaded into the machine to save electric power choose longer washing programs with lower water temperatures washing program duration may vary depending on the actual weight and properties of the laundry system water temperature and hardness and other parameters 45

Note the wash end delay function is not available for some programs 45

Silent mode for disabling the audio signals simultaneously hold down the speed and smart buttons for 3 seconds all signal and alarm sounds will be disabled re activate the sounds in the same way 45

Summary table of washing program parameters 45

Washing temperature selection by repeatedly pressing the temperature button you can select one of the available temperature if this is provided by the program 45

Cleaning the washing agent tray and its compartments 47

Cleaning the water intake filter 47

Close the valve and disconnect the tube from it 2 disconnect the water supply tube from the washing machine pull out the filter with long pliers 3 clean the water intake filter 4 refit the filter and reconnect the water supply tube 5 clean the filter every 3 month to ensure proper operation of the washing machine 47

Note clean the valve filter first then the filter in the washing machine 47

Note do not use alcohol solvents and chemicals for cleaning it is recommended to clean the washing agent tray every 3 months 47

Press the latch located above the rinser conditioner compartment and remove the tray 2 rinse the tray with water 3 clean the inside of the compartment with an old toothbrush or something similar 4 reinstall the tray and return it to its original position 47

Troubleshooting 47

Certification data guarantee the service life of this item is 10 years since the date of sale to the end user provided the item will be used in strict accordance with the present manual and the applicable technical standards upon expiry of the service life please contact the nearest authorized service centre for suggestions as to further operation of the appliance the manufacturing date of the appliance is integrated into the serial number digits 2 and 3 year digits 4 and 5 month of manufacture if any questions related to appliance maintenance should arise or if the appliance has malfunctions apply to the centek tm authorized service center the address of the service center can be found on the website https centek ru servis service support contacts phone 7 988 24 00 178 vk vk com centek_krd general service center ooo larina servis krasnodar phone 7 861 991 05 42 the product has the certificate of conformity no еаэс ru с cn нв62 в 0884 22 of 27 2 022 48

Dear valued consumer the guarantee period for all appliances amounts to 36 months since the date of sale to the end consumer with this warranty card the manufacturer confirms the proper condition of the appliance and undertakes to repair free of charge all defects caused by the manufacturer s default 48

Disposal upon expiry of its service life the appliance can be disposed of separately from ordinary domestic waste you can turn it over to a specialized electric and electronic appliance disposal and recycling centre 48

Error indication in some cases malfunctions can be detected by the washing machine s microcomputer control system warnings are issued as audio signals and error codes displayed 48

Guarantee maintenance terms 48

Manufacturer and importer information imported to eaeu by ooo larina elektroniks address russia 350080 krasnodar ul demusa 14 phone 7 861 2 600 900 48

Note always verify the cause of the malfunction and rectify it before resuming machine operation press start pause once again if the error code disappears the machine will continue working if the error code is till displayed please disconnect the machine from power supply and contact a service center without delay the contents of garment pockets may block the drain hose or cause damage to the machine do not wash clothes that do not have care instruction tags as well as garments not meant for machine washing 48

Specificaions 48

The guarantee shall be valid if the following documentation conditions are observed the original warranty card shall be filled out correctly and clearly indicating the of appliance model serial number and sale date the stamp of the seller company and signature of its representative shall be available as well as the stamps on each coupon and the buyer s signature in the warranty card the manufacturer reserves the right to reject guarantee maintenance if the buyer fails to provide the abovementioned documents or if the information contained therein is incomplete illegible or ambiguous 2 the guarantee shall be valid if the following operation conditions are observed the appliance is used in strict accordance with the present manual the safety rules and requirements are observed 3 the guarantee does not apply to regular maintenance cleaning installation and setup of the appliance at the owner s location 48
