4 English

CHANGE OF BATTERIES

Open battery compartment. Insert batteries. Take care to correct polarity.

Close battery compartment. ATTENTION: If you are not going to use instru-

ment for a long time, take out batteries.

OPERATION

Cube 3D is a reliable and convenient line laser. It will be irreplaceable line

laser for many years. Place the line laser on the working surface or mount

it on the tripod/pillar or wall mount. Switch on the line laser. Visual alarm

(blinking line) and audible signal indicate that the device was not installed

within the compensation range ± 3º. To properly work align the unit in a hor-

izontal plane. Turn the compensator switch (3) to the position “ON” (the line

laser is turned o in the position OFF). At that compensator of the line laser

will be in free position (it will be blocked in the position OFF). When switching

on, one horizontal and one vertical lines will be projected. Press button (6)

to turn on additional vertical line. Press button (6) again to have only one

additional vertical line. Press button (6) one more time to turn o additional

vertical line and switch on horizontal line.

Use the receiver (supplied separately) mode to enlarge the working mode

and for the operation in bright illumination. Press and hold button (6) for

more than 2 sec to switch on the receiver mode. The mode is activated after

the sound alarm. Press and hold button (6) for more than 2 sec again to

switch o the receiver mode.

TO CHECK THE ACCURACY OF LINE LASER (SLOPE OF PLANE)

Set up the line laser between two walls, the distance is 5m.Turn on the line

laser and mark the point of cross laser line on the wall. Set up the line laser

0,5-0,7m away from the wall and make, as described above, the same mas-

rks. If the dierence {a1-b2} and {b1-b2} is less then the value of
