“accuracy” (see spesications), there is no need in calibration. Exam-

ple: when you check the accuracy of Cross Line Laser the dierence

is {a1-a2}=5 mm and {b1-b2}=7 mm. The line laser’s error: {b1-b2}-

{a1-a2}=7-5=2 mm. Now you can compare this error with standard error.

If the accuracy of line laser isn’t corresponding with claimed accuracy,

contact the authorized service center.

TO CHECK THE ACCURACY OF HORIZONTAL BEAM

Choose a wall and set laser 5M away from the wall. Turn on the laser and

cross laser line is marked A on the wall. Find another point M on the hori-

zontal line, the distance is around 2.5m. Swivel the laser, and another cross

point of cross laser line is marked B. Please note the distance of B to A

should be 5m. Measure the distance between M to cross laser lune, if the

dierence is over 3mm, the laser is out of calibration, please contact with

seller to calibrate the laser

TO CHECK PLUMB

Choose a wall and set laser 5m away from the wall. Mark point A on the

wall, please note the distance from point A to ground should be 3m. Hang

a plumb line from A point to ground and nd a plumb point B on ground.

Turn on the laser and make the vertical laser line meet the point B, along

the vertical laser line on the wall and measure the distance 3m from point

B to another point C. Point C must be on the vertical laser line, it means

theheight of C point is 3m. Measure the distance from point A to point C, if

the distance is over 2 mm, please, contact with seller to calibrate the laser.

CARE AND CLEANING

Please handle line laser with care. Clean with soft cloth only after any use.

If necessary damp cloth with some water. If instrument is wet clean and

dry it carefully. Pack it up only if it is perfectly dry. Transport in original con-

tainer/case only. Note: During transport On/O compensator lock (5) must

be set to position “OFF”. Disregard may lead to damage of compensator.
