3English

THE MANUFACTURE RESERVES THE RIGHT TO MAKE CHANGES (NOT

HAVING AN IMPACT ON THE SPECIFICATIONS) TO THE DESIGN, COMPLETE

SET WITHOUT GIVING PRIOR WARNING.

APPLICATION

Line laser ADA TOPLINER 3-360 GREEN is designed to check the horizontal

and vertical position of the surfaces of the elements of building structures

and also to transfer the angle of inclination of the structural part to similar

parts during construction and installation works.

SPECIFICATIONS

Laser beam ...........................................2V1H (360° laser)

Light sources.........................................532 nm

Laser safety class.................................Class 2, <1mW

Accuracy ...............................................±3 mm/10 m

Self-leveling range...............................±4.5°

Working range (with detector).........40m (70m)

Rotation/Fine adjustment ................360 °/ ±10° (with rotation base)

Power supply........................................Li-ion accumulator

Service time .........................................approx 5-8 h with all lines ON

Mounting thread ................................1/4 ″ and 5/8 ″

Operating temperature................... -10°C ~ +40°C

Weight ..................................................0.9 kg

FUNCTIONAL DESCRIPTION

Emitting a horizontal and two vertical laser line. Quick self-leveling: when

line accuracy is out of the range the laser line ashes and the warning

sound is produced. Compensator locking system for safe transportation.

Intermediate compensator locking system for slope operation. Indoor

and outdoor performance function.
