5English

MOUNTING THREAD

It is possible to place the instrument on the tripod or wall mount during

operation. For attachement use thread 1/4” at the bottom part of the

instrument or thread 5/8” at the bootom part of the rotating base.

LOCK SWITCH

Lock switch has tree positions:

1. OFF mode Power is OFF. Pendulum is locked. Button panel can

not be used.

2. Tilt mode. Power is ON. Pendulum is locked. Button panel can be used.

Vertical lines and horizontal line can be switched on/off.

3. ON mode.Power is on. Pendulum is unlocked. Self-leveling.

Button panel can be used. Vertical lines and horizontal line can be switched

on/off. Detector mode.

POWER WARNING

Power LED flashes when the power is full. Maximum operating time with all

laser beams is about 30 min. All laser beams and LED will be shut off when the

power is very low. Please use the standard charger to charge the instrument.

CHARGER LED

The LED of the charger will be yellow when it’s charging. When power is full,

the indicator changes into green light. The Charger should be 5V 1A . The

instrument can be used while charging.

TILT MODE WARNING

The instrument can work in the tilt mode (intermediate position of lock switch).

Tilt LED flashes. Pendulum is locked. Laser lines are projected at any angle.

For example, when making stairs.
