Stanley STSC1860-RU [8/20] Accessories
![Stanley STSC1860-RU [8/20] Accessories](/views2/1881904/page8/bg8.png)
● Tighten the shoe retaining bolt (12) with the hex key
provided to lock the shoe plate (5) in the required position.
Note: The shoe can be beveled to the left or to the right and
has detents at 45°.
Cutting action (g. I)
This jig saw is equipped with three cutting actions, two orbital
and one straight. Orbital action has a more aggressive blade
motion and is designed for cutting in soft materials like wood
or plastic. Orbital action provides a faster cut, but with a less
smooth cut across the material. In orbital action, the blade
moves forward during the cutting stroke in addition to the up
and down motion.
@
Warning! Metal or hardwoods should never be cut in
orbital action.
● Slide the cutting action button (6) between the three
cutting positions: 0, 1 and 2.
● Position 0 is for straight cutting.
● Positions 1 and 2 are for orbital cutting.
● The aggressiveness of the cut increases as the lever
is adjusted from one to two, with two being the most
aggressive cut.
Sawing
● Always hold the tool with both hands.
● Let the blade run freely for a few seconds before starting
the cut.
● Apply only a gentle pressure to the tool while performing
the cut.
● If possible, work with the shoe plate (5) pressed against
the workpiece. This will improve tool control and
reduce tool vibration, as well as prevent the blade from
being damaged.
Hints for optimum use
General
● Use a high speed for wood, a medium speed for
aluminium and PVC and a low speed for metals other
than aluminium.
Sawing laminates
As the saw blade cuts on the upward stroke, splintering may
occur on the surface closest to the shoe plate.
● Use a ne-tooth saw blade.
● Saw from the back surface of the workpiece.
● To minimise splintering, clamp a piece of scrap wood or
hardboard to both sides of the workpiece and saw through
this sandwich.
Sawing metal
Be aware that sawing metal takes much more time than
sawing wood.
● Use a saw blade suitable for sawing metal. Use a ne-
tooth saw blade for ferrous metals and a coarser saw
blade for non-ferrous metals.
● When cutting thin sheet metal, clamp a piece of scrap
wood to the back surface of the workpiece and cut
through this sandwich.
● Spread a lm of oil along the intended line of cut.
Accessories
The performance of your tool depends on the accessory used.
STANLEY accessories are engineered to high quality standards
and designed to enhance the performance of your tool. By using
these accessories you will get the very best from your tool.
This tool is suitable both for U-shank and T-shank saw blades.
Maintenance
Your STANLEY tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regular cleaning.
Your charger does not require any maintenance apart from
regular cleaning.
@
Warning! Before performing any maintenance on the
tool, unplugremove the battery from the tool. Unplug
the charger before cleaning it.
● Regularly clean the ventilation slots in your tool and
charger using a soft brush or dry cloth.
● Regularly clean the motor housing using a damp cloth.
Do not use any abrasive or solvent-based cleaner.
Protecting the environment
Z
Separate collection. Products and batteries
marked with this symbol must not be disposed of
with normal household waste.
Products and batteries contain materials that can be
recovered or recycled, reducing demand for raw materials.
Please recycle electrical products and batteries according
to local provisions. Further information is available at
www.2helpU.com
Technical data
STSC1860
Voltage V
dc
18
No-load speed min
-1
0 - 2500
Stroke length
mm 19
Max depth of cut
Wood
mm 55
Steel
mm 8
Aluminium
mm 20
Weight kg
2.62
8
ENGLISH
(Original instructions)
9
ENGLISH
(Original instructions)
