26
English
23 Body vertical position adjustment bolt lock-nut
24 Base plate
25 Ventilation slots
26 Speed selector thumbwheel
27 Allen key *
28 Parallel guide *
29 Guide rail *
30 Internal ange
31 Spindle
32 Adjusting bolt of riving knife
33 Nut of body tilt angle indicator
* Optional extra
Not all of the accessories illustrated or described
are included as standard delivery.
Installation and regulation of power tool
elements
Before carrying out any works on the power tool it
must be disconnected from the mains.
Do not draw up the fastening elements
too tight to avoid damaging the thread�
Mounting / dismounting parallel guide (see g. 1)
• Loosen xing screws 4 (see g. 1.1).
• Install, remove or move parallel guide 28�
• Tighten xing screws 4 (see g. 1.2).
Using guide rail (see g. 2-3)
• Mount the power tool on the guide rail 29 (see
g. 2.1).
• There are two grooves for power tool mounting
on the guide rail 29 on the base plate 24� Select the
groove for mounting depending on the type of cuts to
be made (vertical or inclined, see g. 3).
• Rotate the eccentric screws 1 to adjust power tool
movement along the guide rail 29 (see g. 2.2).
Replacement of the saw blade (see g. 4-6, 9)
After prolonged operation, the saw blade
can become very hot, remove it using
gloves. This will also reduce the risk of
injury by the cutting edge.
• Set the maximum depth of cut (see g. 9.1).
• Move the lock button 3 as shown in gure 9.2 and
lower the tool body down� The bolt 14 shall be in front
of the hole on the side surface of the guard cover 7
(see g. 4).
• Mount power tool on the side end of the motor as
shown in g. 4.
• Press down spindle lock 21 and rotate saw blade 12
manually in order to lock it in a xed position. While
pressing down spindle lock 21, unscrew bolt 14 with
the help of Allen key 27�
• Remove from spindle 31: external ange 13, saw
blade 12, internal ange 30�
• Clean all xing elements with a soft brush and mount
on the spindle 31: internal ange 30, saw blade 12, ex-
ternal ange 13, screw in bolt 14 manually�
Attention! observe the following rules during
installation:
• follow the mounting sequence (see g. 6);
• avoid bending during mounting;
• before mounting saw blade 12, make sure that the
mounting opening diameter ts the diameter of the
projected parts of internal ange 30;
• arrow direction marked on saw blade 12 should co-
incide with arrow direction on guard cover 7;
• mount external ange 13 with bevel edge outwards�
• Press and hold spindle lock 21 and tighten bolt 14
with Allen key 27� Release spindle lock 21�
Regulation of riving knife position (see g. 7, 9)
It is necessary to check the correct position of the
riving knife 11 after each replacement of the saw
blade 12� The riving knife 11 shall be mounted as fol-
lows:
• the distance between the riving knife 11 and the
teeth of the saw blade 12 shall not exceed 5 mm;
• the distance between the top of the lowest tooth
of the saw blade 12 and the lower point of the riving
knife 11 shall not exceed 5 mm�
• Set the maximum depth of cut (see g. 9.1).
• Move the lock button 3 as shown in gure 9.2 and
lower the tool body down� The adjusting bolt 32 shall
be located opposite the hole on the side surface of the
guard cover 7 (see g. 7.1).
• Loosen the bolt 32 with a Allen key 27�
• Move the riving knife 11 to adjust the clearance
between the riving knife 11 and the saw blade 12 (see
g. 7.2). If it is impossible to make this adjustment (for
example, if the saw blade 12 is worn), use another saw
blade 12�
• Tighten the bolt 32 with a Allen key 27�
Regulation of body vertical position (see g. 8-10)
• Loosen xing screws 5 (see g. 10.1).
• Install the body of the power tool vertically�
• Tighten xing screws 5�
• Set the maximum depth of cut (see g. 9.1).
• Move the lock button 3 as shown in gure 9.2 and
lower the tool body down�
• Place the sides of an alignment setsquare 90° to
the surface of saw blade 12 and base plate 24 (see
g. 8.1). If the setsquare sides join the surfaces of saw
blade 12 and base plate 24, tightly, then alignment is
not needed, otherwise you have to adjust the position
by screw 22 and lock-nut 23 (see g. 8.3).
• Loosen xing screws 5�
• Loosen lock-nut 23�
• Turning the screw 22 in or out, make the sides of
the 90° setsquare join the surfaces of saw blade 12
and base plate 24 tightly�
• Holding screw 22, tighten lock-nut 23�
• After this adjustment make sure the indicator 16
points exactly to "0°" on the scale 15� If not, loosen the
nut 33, move the indicator 16 to "0°" of the scale 15
and tighten the nut 33 (see g. 8.2).
Initial operation of the power tools
Always use the correct supply voltage: the power
supply voltage must match the information quoted on
the power tool identication plate.
