Festool CTH 26 E / a 574939 [16/123] Technical data

Warning contains asbestos

Socket with automatic switch-on

unit

WARNUNG

≤ 0,1 mg/m

(dust class H)

3 Technical data

Mobile dust extractors

Power consumption 350 ‑ 1000 W

Maximum appliance socket connected load EU

CH, DK

GB 240 V/ 110 V

2400 W

1100 W

1800 W/ 500 W

Max. suction capacity (air), turbine

[3]

234 m³/h (3900 l/min)

Max. vacuum, turbine

24000 Pa

Filter surface area 6318 cm²

Suction hose D 27 / 32 mm x 3,5 m AS

Length of the net cable 7,5 m

Sound pressure level as per EN 60704-2-1 / Uncertainty K 71 dB(A) / 3 dB

Protection category IP X4

Container capacity CTH 26 E/a 26 l

CTH 48 E/a 48 l

Dimensions L x W x H CTH 26 E/a 630 x 365 x 540 mm

CTH 48 E/a 740 x 406 x 1005 mm

Weight CTH 26 E/a 13,9 kg

CTH 48 E/a 18,8 kg

Volume flow at least

/h]

[l/s]

21 mm 25 6,9

27 mm/ IAS 41 11,4

32 mm 58 16,1

36 mm 73 20,3

42 mm 100 27,8

50 mm 141 39,2

[3] The suction capacity and vacuum are dependent on the selected hose diameter. For more information please refer to page 7.

English
