Zyxel ES-116S [5/29] Wall mounting optional

ENGLISH

5 Wall Mounting (optional)

See the product specifications for the size of screws to

use and how far apart to place them.

1 Locate a high position on wall that is free of

obstructions. Use a sturdy wall.

2 Drill two holes for the screws. Make sure the distance

between the centers of the holes matches what is

listed in the product specifications appendix.

" Be careful to avoid damaging pipes or

cables located inside the wall when drilling

holes for the screws.

3 Do not screw the screws all the way into the wall.

Leave a small gap of about 0.5 cm between the heads

of the screws and the wall.

LINK/

ACT

On The port is connected to an Ethernet

network.

Blinking The port is receiving or transmitting data.

Off The port is not connected to an Ethernet

network.

LED Status Description
