20
KS 60 E
GB
4Technical data
5 Machine features
6 Commissioning
6.1 Initial operation
Ensure that the power tool is securely posi-
tioned. Risk of tipping over. If required, ob-
serve the assembly instructions for the MFT
multifunction table or base frame UG-KAPEX
KS 60.
Remove the transport safety device
[3]
.
Remove the protective sleeve from the left-
hand pulling rail .
Push the saw unit down, thus breaking
through the cable ties that are securing it in
place .
Remove the clamp from around the tilt lock-
ing device .
Set up the machine and move it into the working
position.
6.2 Setting up and securing [5]
Pull out the mains plug before you carry out
any work on the machine.
Before securing, if required, install the A-SYS-KS60
support legs (optional accessory). Thanks to these
support legs, the work surface on the rotary base is
at the same height as a Systainer 1. These Systain-
ers mean that long workpieces can then be sup-
ported
[5]
.
You have the following options for securing:
Secure the machine in such a way that it can-
not move when you are working on it.
Screws[5A]
: Use four screws to secure the ma-
chine to the work surface. Use the holes
[5A-1]
at
the four support points on the saw table to do this.
Clamps[5B]
: Use clamps
[5B-1]
to secure the ma-
chine to the work surface. The support points are
used to reliably secure the machine while taking
the centre of gravity into consideration.
Sliding compound mitre
saw
KS 60 E
Power 1200 W
Power supply 220-240 V~ 50/60 Hz
No-load speed 1300 - 3500 rpm
Max. speed
1
1.
Max. speed in the event of faulty electronics.
5000 rpm
Max. mitre angle 60° left/right
Max. inclination angle 47/46° left/right
Saw blade dimensions 216 x 2,3 x 30 mm
Weight 17,8 kg
Safety class /II
[1-1]
Handle
[1-2]
Safety button
[1-3]
On/Off switch
[1-4]
Lever for groove depth limit
[1-5]
Rotary knob for slide locking device
[1-6]
Lever for transport locking device
[1-7]
Spindle stop
[1-8]
Stop ruler (both sides)
[1-9]
Rotary knobs for securing the table exten-
sion (both sides)
[1-10]
Angle display for mitre cuts
[1-11]
Lever for locking the mitre angle
[1-12]
Rotary base
[1-13]
Pendulum guard
[2-1]
Cable clamp
[2-2]
Extractor connector
[2-3]
On/off switch for spotlight (available as an
accessory depending on the model)
[2-4]
FSZ120 fastening screw clamp
[2-5]
Adjusting wheel for setting the speed
[2-6]
Rotary knob for securing the rotary base
[2-7]
Table extension (both sides)
[2-8]
Bevel holder for clamping the bevel
[2-9]
Star handle for securing the inclination
angle
[2-10]
Key storage box for the Allen key
[2-11]
Cable winder with integral carry handle
[3]
Remove the transport safety device
[4]
Insulated gripping surfaces (grey shaded
area)
WARNING
Unauthorised voltage or frequency!
Risk of accidents
Observe the specifications on the machine’s
name plate.
Observe country-specific regulations.
