11
English
NAMES OF PARTS (Fig. 1 – Fig. 15)
1
Motor
^
Battery level indicator
switch
2
Nameplate
&
Battery level indicator
lamp
3
Lock pin
*
Lever
4
Side handle
(
Hex. bar wrench
5
Gear cover
)
Wheel washer (E)
6
Depressed center
wheel
q
Wheel nut
7
M5 hex. socket bolt
w
Wrench
8
Wheel guard
e
With side guard
9
Filter
r
Abrasive cutting
wheel
0
Switch lock
t
Lock lever
!
Switch
y
Mode indicator lamp
@
Auto mode indicator
switch
u
Rubber cover
#
Battery
i
USB port
$
Latch
o
USB cable
%
Charge indicator lamp
SYMBOLS
WARNING
The following show symbols used for the machine.
Be sure that you understand their meaning before
use.
G3623DA: Cordless Disc Grinder
To reduce the risk of injury, user must read
instruction manual.
Always wear eye protection.
Only for EU countries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive 2002/96/EC
on waste electrical and electronic equipment and
its implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility.
V Rated voltage
n
Rated speed
n
0
No-load rotation speed
min
-1
Revolution or reciprocations per minute
Switching ON
Switching OFF
Lock
Switching locks to the "ON" position
Disconnect the battery
Warning
Remaining battery indicator switch
Battery
Lights ;
The battery remaining power is over 75%
Lights ;
The battery remaining power is 50% – 75%.
Lights ;
The battery remaining power is 25% – 50%.
Lights ;
The battery remaining power is less than 25%
Blinks ;
The battery remaining power is nearly empty.
Recharge the battery soonest possible.
Blinks ;
Output suspended due to high temperature.
Remove the battery from the tool and allow it to
fully cool down.
Blinks ;
Output suspended due to failure or malfunction.
The problem may be the battery so please
contact your dealer.
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package contains the
accessories listed on page 291.
Standard accessories are subject to change without notice.
APPLICATIONS
○ Removal of casting fi n and fi nishing of various types of
steel, bronze and aluminum materials and castings.
○ Grinding of welded sections or sections cut by means of
a cutting torch.
○ Grinding of synthetic resins, slate, brick, marble, etc.
SPECIFICATIONS
1. Power tool
Model
G3623DA
Voltage 36 V
Rated speed
5300 min
-1
Auto mode: 3200 min
-1
Wheel
Outer dia. 230 mm
Hole dia. 22.23 mm
Thickness 6 mm
Peripheral speed 80 m/s
Battery available for this tool* BSL36B18
Weight** 4.9 kg
