HD135
4
The specifications of any product may change without prior notice to improve performance.
3. Components
Top Cover
ODD Bracket
Body
External
Drive Cover
HDD
Bracket
HDD
Bracket
Fan & Air Duct
1) HD135 Body
2) Case Parts
3) M-Play Parts
24 HDD / Power Supply Bolts
(PH #6-32X6) 24
ODD / FDD / Motherboard
Bolts (PWH M3X5)
2 microATX Standoffs (M3)
1 ODD Aluminum Bezel
1 Clamp
1 User's Manual
1 Remote Controller
2 Batteries (AAA)
1 Installation CD
1 User's Manual
