ENGLISH
½ Enclosure Type - Desktop
½ Dimensions (LXWXH) - 435mm X 425mm X 135mm
(17.1inch X 16.7inch X 5.31inch)
½ Weight - 5.2kg (11.5lb)
½ Material - Aluminum
½ Motherboard Compatibility - ATX / microATX
½ Power Supply Support - ATX / ATX 12V
½ PCI/AGP Card Support - Full Size
½ Drive Bays - 5 X 3.5" Internal Drive Bays
- 1 X 3.5" External Drive Bay
- 1 X 5.25" External Drive Bay
½ Cooling Components - 1 X 80mm Exhaust Fan
- 1 X 80mm Inflow Fan and Air Duct
½ Expansion Slots - 7 Slots
½ Front I/O Ports - 2 X USB Ports
- 1 X IEEE1394(Firewire) Port
- 1 X MIC
- 1 X Headphone
½ Available Colors - Silver / Black
½ Display Type - VFD (Vacuum Fluorescent Display)
5. Specifications
The specifications of any product may change without prior notice to improve performance.
HD135
7
