Buffalo TS-2RZH36T12D [17/160] Recovery drive

Recovery Drive

1 Insert a 1 GB or larger USB flash drive into a USB port on the TeraStation.

Note: All data on the USB flash drive will be erased!

2 In Settings, navigate to Management - Restore/Erase - USB Options.

3 Select “Create a USB drive for system recovery”.

4 Select the USB drive connected to the TeraStation from “Target USB drive”, then click Execute. Enter the 4 digit

confirmation number and click OK. The TeraStation will create the recovery drive. This will take about a minute.

5 When the “finished” dialog opens, the USB recovery drive is ready to use. Dismount the USB drive before

unplugging it.

For the instructions on recovering the TeraStation using the drive you just created, turn to chapter 10.
