Chapter1 Setup
LinkStation Setup Manual
1212
Back
Diagrams and Layout (LS-WXL)
The following list shows the name of each component of the LinkStation.
Front
1
1 Power LED
Blue LED: Power on.
LED is o: Power o.
Blinks blue: During startup / shutdown.
2 Function LED
The Function LED glows blue when direct copy is nished, during initialization, and during
USB dismounting (about 60 seconds). During direct copy the Function LED blinks blue.
3 Info/Error LED
The Info/Error LED blinks orange when there’s a message and red when there’s an error.
4 Function Switch
The Function Switch initiates direct copy, dismounts USB devices, and is used to initialize the
LinkStation.
2
3
4
5
6
7
8
9
10
12
11
Note: – Please do not lift the LinkStation by its front cover. It might come o.
