LinkStation Setup Manual
7171
Appendix
Specications
Check Bualo's catalogs or web site (www.bualotech.com) for information about the latest prod-
ucts or compatible models.
Interface
(LAN port)
Interface: Complied with IEEE802.3ab (1000BASE-T)
Complied with IEEE802.3u (100BASE-TX)
Complied with IEEE802.3 (10BASE-T)
Transfer Speed:1000Mbps Full duplex (AutoNegotiation)
100Mbps Full duplex/Half duplex (auto-negotiation),
10Mbps Full duplex/Half duplex (auto-negotiation),
Number of ports:1 port (support AUTO-MDIX)
Connector type:
RJ-45 8-pin
Access method:
CSMA/CD
Protocol:
TCP/IP
Network File Systems: SMB/CIFS, AFP, FTP, HTTP/HTTPS
Jumbo Frame frame length: 1,518/4,102/7,422/9,694 Bytes(Including 14
bytes of the header and 4 bytes of FCS)
Interface
(USB Connector)
Interface: USB Standard Revision 2.0
Data transfer speed: Maximum 480 Mbps (Theoretical value)
Connector: USB connector (Series A) X 1
Supporting USB devices: USB hard disk manufactured by Bualo, USB UPS,
USB printer and etc. Please ensure the supported USB UPS on Buffalo's
website (www.bualotech.com).
Power/ Consumption power
AC100V 50/60Hz /
LS-XHL,CHL: Approximately 24 W (Maximum) Approximately 17 W (Average)
LS-WXL: Approximately 48 W (Maximum) Approximately 26 W (Average)
LS-WSXL: Approximately 15 W (Maximum) Approximately 9 W (Average)
External size / Weight
LS-XHL,XHL: W45 X H175 X D156 mm (excluding protruding parts) / about 1.1 kg
LS-WXL: W86 X H127 X D204 mm (excluding protruding parts) / about 2.3 kg
LS-WSXL: W40 X H82 X D135 mm (excluding protruding parts) / about 0.5 kg
Operating Environment
Temperature 5 - 35 °C / Humidity 20 - 80 % (no condensation)
Comp ati -
ble Models
C o m p a t i b l e
computer
IBM/PC Compatible (OADG spec), NEC PC98-NX Series, Apple Mac Series
NOTE: Equipped with LAN interface.
• The LinkStation cannot be connected with computers via USB; It is only
connected via LAN.
Compatible OS
Windows 7/Vista/XP/2000, Windows Server2003/Server2008,
Mac OS X 10.3.9 or later
